MRC Fuego SCS basic Operation Manual page 2

7a
7
3
4
5
2a
2
8 - Connector for foot pedal (Cable)
9 - Power connector for 9 V DC
10 - Gas inlet R 1/4" L (left hand thread)
11 - Holding device for inoculation loop holder
13
12
15 - Active nozzle
16 - Nozzle holder for alternative gas
17 - Cover of the burner shaft
18 - Retaining screw for
cover of the burner shaft
18a- Position scew for the cover
19 - Guide slots for tilt adjustment
21 - Battery compartment (2 x AA, Mignon)
21a - Transport insulation for the batteries
1 - Function knob
2, 2a - Dual knob: 2 - Gas adjustment
3 - LED Standard
4 - LED StartStop
6
5 - LED Button
1
6 - LED Burner head HOT / BHC
7 - Burner head
7a - Flame orifice
12 - Burner head screw
13 - Monitor electrode
14
14 - Ignition electrode
20 - Function LED and programming key
20
2a - Air adjustment
8
9
18a
15
16
17
19
18
11
10
19
21
21a
