Setup - Network Setup

SNMP Settings

1
2
3
4
5
6
7
8
9
10
11
SNMP is for advanced users only.
SNMPv1/SNMPv2 - Select the SNMPv1/SNMPv2 option and type the names of Read community and Write community.
1
SNMP trap can be used to check periodically for operational thresholds or failures that are defined in the MIB.
SNMP Trap - SNMP trap can be enabled or disabled.
2
SNMPv3 contains cryptographic security, a higher security level, which allows you to set the Authentication password and the
Encryption password.
Mode - Select either Read or Read/Write mode.
3
Activation - Disable or activate the selected mode.
4
Read/Write name - Define Read name and Write name.
5
Security Level - Select one of no auth, no priv/auth , no priv/auth, priv
6
Authentication Algorithm - Select MD5 or SHA as the authentication method.
7
Authentication Password - The Authentication Password is an encrypted password used for authentication. A minimum of 8
8
digits required and a maximum of up to 30 digits allowed.
Private-Key Algorithm - Select DES or AES as the encryption algorithm.
9
Private-Key Password - Information protection password is a private encrypted password. A minimum of 8 digits required and a
10
maximum of up to 30 digits allowed.
Click Apply to save new settings.
11
