Ptz Settings - 3xLogic VISIX Gen III Series User Interface Manual

Setup - PTZ Setup

PTZ Settings

1
2
3
4
5
6
PTZ Settings are only available for applicable models.
Parking Action - Set the action for the camera to take when the PTZ control of the camera is not in use.
1
▪
Wait Time : Set the wait time (5sec ~ 14400sec). The camewra will be considered idle after the set amount of
time transpires with no PTZ inputs detected.
▪
Action : Set the action to perform if there is no PTZ operation during the wait time. (HomePosition / Preset /
Preset Tour)
▪
Preset : If the Action is set to a preset, select the preset number here. Presets must be constructed and added
from the main viewer.
▪
Preset Tour : If the Action is set to a preset tour, it can be selected here. Preset Tours can be constructed and
added from the main page.
Click Apply to save new settings.
2
Power Up Action - Set the acti for PTZ to take when the camera comes online.
3
- Action : Set the action (HomePosition / Preset / Preset Tour)
- Preset : If the Action is set to a preset, select the preset number here. Presets must be constructed and added
from the main viewer.
- Preset Tour : If the Action is set to a preset tour, it can be selected here. Preset Tours can be constructed and
added from the main page.
Click the 'Apply' to make above setting effective.
4
AutoFlip & Digital Zoom
5
- AutoFlip : This is a function that enables continuous pan by converting PTZ to 180 degree panoraamic instantly.
- Digital Zoom : Enable this to allow Digital zoom.
Click Apply to save new settings.
6
