Camera Day & Night Settings - 3xLogic VISIX Gen III Series User Interface Manual

Setup - Camera Setup
Camera Day & Night Settings
1
2
3
4
Day & Night
1
- Auto: In this mode, the IR cut filter is applied automatically depending on the light conditions of the environment.
- Day: In this mode, the IR cut filter is applied to the image sensor at all times.
Thus, the sensitivity will be reduced in dark light conditions but better color reproduction performance is obtained.
- Night: In this mode, the IR cut filter on the image sensor isalwyas disabled
The sensitivity will be enhanced in dark light conditions but the image is black and white.
- Schedule: In this mode, Day / Night mode is converted in accordance with the scheduled time.
Schedule
- Day > Night Time / Night > Day Time : If it is set to schedule mode, Set the time that Day / Night mode switches.
Color Level - Set the color level threshold for switching Night mode into Day mode when Day & Night mode is set to Auto.
2
B / W Level - Set the Black and White Level threshold for switching change Day mode into Night mode when Day & Night mode
3
is set to Auto.
Click Save to save the current settings.
4
Click 'Cancel' to return to the previous settings.
Click 'Default' to return settings to the factory defaults.
