Setup - Camera Setup

Camera White Balance

1
2
3
Activation - White Balance can be enabled or disabled here. Auto / Indoor / Outdoor / One Push WB / Manual modes available.
1
One Push WB : Clicking the PUSH button saves the white balance value at the current state.
White Balance Mode - Select White Balance depending on the lighting conditions.
2
RB Gain - The R/B gain can be set only when the White Balance Mode is set to Manual.
3
Click Save to save the current settings.
4
Click 'Cancel' to return to the previous settings.
Click 'Default' to return settings to the factory defaults.
