Region Of Interest Configuration - 3xLogic VISIX Gen III Series User Interface Manual

Setup - Video & Audio Setup

Region of Interest Configuration

1
2
3
4
The Region of interest (ROI) function increases picture quality for an indicated area while mainting lower quality for the rest of
the image to help maintain bandwidth usage.
Stream - Select the Stream to apply the ROI to.
1
ROI currently supports only H.264, H.265 (HEVC).
The function is not supported iwith the MJPEG codec.
Activation - The Region of interest can be enabled or disabled here.
2
Quality - Set the quality of the set ROI area.
3
Click Save to save the current settings.
4
Click 'Cancel' to return to the previous setting.
www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com
Pg. 16
