IEEE 802.1X Configuration

1
2
3
4
5
6
7
8
9
The feature is needed when connecting the camera to the network protected by the IEEE 802.1X.
IEEE 802.1x - The IEEE 802.1x feature can be enabled or disabled here.
1
Protocol
2
- MD5: Provides one-way password-based network authentication of the client.
- PEAP : Similair TTLS in that it does not require a certificate on the client side.
- TTLS / MD5 : It does not require a certificate on the client side.
- TLS : It relies on client-side and server-side certificates to perform authentication.
EAPOL Version - Select the EAPOL Version.
3
ID - Type the ID to identify the client in the IEEE 802.1X authentication server.
4
Password - Type the Password to identify the client in the IEEE 802.1X authentication server.
5
Verify - Verify Password.
6
CA Certificate - Select the CA certificate required for TLS, TTLS, and PEAP authentication.
7
Certificate - Select the client certificate required for TLS authentication
8
Click Apply to save new settings.
9
