Ftp Settings - 3xLogic VISIX Gen III Series User Interface Manual

Setup - Network Setup

FTP Settings

1
2
3
4
5
6
7
To transfer / save images to a relevant site via FTP, then FTP must be enabled and configured here.
General Setting - FTP function can be enabled or disabled here.
1
FTP Server Address - Define FTP Server IP Address. If IP Address form is incorrect, a Message box will deploy warning the user.
2
FTP Upload Path - Define a path on the FTP server to store images. For the path name, English Alphabets, numbers and special
3
characters ( / ~ !@ $ ^ ( ) _ - { } [ ] ; , ) can be used.
FTP Port - Define the FTP Server Port. If no port is available, it is impossible to access the FTP Server from the camera.
4
User ID - Enter a User ID to access the FTP Server. Fill out using the correct User ID registered in the FTP Server.
5
Password - Enter a Password to access to the FTP Server. Fill out using the correct Password registered in the FTP Server.
6
Click Apply to save new settings.
7
Refer the above screen image for the example.
www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com
Pg. 35
