Motion Detection Configuration - 3xLogic VISIX Gen III Series User Interface Manual

Setup - Event Setup

Motion Detection Configuration

1
2
3
4
5
Motion Detection - Shows the Motion event status.
1
Event Alert Icon( ) appears if 'Motion Detection' is activated.
Area - Set the motion detected area.
2
You can set up to four areas.
Activation - Enable or Disable motion detection.
3
Sensitivity - Define the sensitivity of motion detection.
4
If a High value is selected, it will detect very small motions while conversely, it becomes insensitive to motion when a Low value
is selected.
Click Save to save the current settings.
5
Click 'Cancel' to return to the previous settings.
www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com
Pg. 46
