Levelflex FMP51 Modbus
Endress+Hauser
Accessories Description
Centering weight 316L
•  75 mm (2.95 in)
•  95 mm (3.7 in)
suitable for
FMP51
A = 52.5 mm (2.07 in) for DN80/3" pipe
B
The centering weight is suitable for probes with a rope diameter of 4 mm (¹⁄₆ in)
and can be used in DN80/3" or DN100/4" pipes.
• Material: 316L
• Order number
– 71420822 (for DN80/3" pipe)
– 71420824 (for DN100/4" pipe)

Ø5,5 (0.22)
= 62.5 mm (2.47 in) for DN100/4" pipe
= 75 mm (2.95 in) for DN80/3" pipe
= 95 mm (3.7 in) for DN100/4" pipe
The centering weight can also be ordered directly with the device (Levelflex
product structure, feature 610 "Accessory mounted", option OL (for DN80/3"
pipe) or OM (for DN100/4" pipe)).
Ø20 (0.79)
ØA
Ø30 (1.18)
Ø8 (0.31)
11 (0.43)
ØB
A0038924
