Certificates And Approvals; Ce Mark; Rohs; Rcm-Tick Marking - Endress+Hauser Levelflex FMP51 Modbus Technical Information

CE mark

RoHS

RCM-Tick marking

Ex approval

Dual seal according to
ANSI/ISA 12.27.01

Overfill prevention

AD2000

NACE MR 0175 / ISO 15156

NACE MR 0103

ASME B31.1 and B31.3

Pressure equipment with
allowable pressure
≤ 200 bar (2 900 psi)
70

Certificates and approvals

Currently available certificates and approvals can be called up via the product configurator.
The measuring system meets the legal requirements of the applicable EC guidelines. These are listed
in the corresponding EC Declaration of Conformity together with the standards applied.
Successful testing of the device is confirmed by affixing to it the CE mark.
The measuring system complies with the substance restrictions of the Restriction on Hazardous
Substances Directive 2011/65/EU (RoHS 2).
The supplied product or measuring system meets the ACMA (Australian Communications and Media
Authority) requirements for network integrity, interoperability, performance characteristics as well
as health and safety regulations. Here, especially the regulatory arrangements for electromagnetic
compatibility are met. The products are labelled with the RCM- Tick marking on the name plate.
The devices are certified for use in hazardous areas and the relevant safety instructions are provided
in the separate "Safety Instructions" (XA) document. Reference is made to this document on the
nameplate.
The devices have been designed according to ANSI/ISA 12.27.01 as dual seal devices, allowing the
user to waive the use and save the cost of installing external secondary process seals in the conduit
as required by the process sealing sections of ANSI/NFPA 70 (NEC) and CSA 22.1 (CEC) These
instruments comply with the North-American installation practice and provide a very safe and cost-
saving installation for pressurized applications with hazardous fluids.
Further information can be found in the Safety Instructions (XA) of the relevant devices.
WHG
DIBt Z-65.16-501
• The wetted material 316L (1.4435/1.4404) corresponds to AD2000 - W2/W10.
• Declaration of conformity: see product structure, feature 580, option JF.
• The wetted, metallic materials (except for ropes) comply with the requirements of NACE MR
0175 / ISO 15156.
• Declaration of conformity: see product structure, feature 580, option JB.
• The wetted, metallic materials (except for ropes) comply with the requirements of NACE MR
0103 / ISO 17495.
• The certificate of compliance is based on NACE MR 0175.
The hardness and the intercrystalline corrosion have been tested, as well as the heat treatment
(solution annealed) has been carried out. The used materials comply therefore with the
requirements of NACE MR 0103 / ISO 17495.
• Declaration of conformity: see product structure, feature 580, option JE.
• The dimensions, materials of construction, pressure / temperature ratings and identification
markings of the device comply with the requirements of AMSE B31.1 and ASME B31.3
• Declaration of conformity: see product structure, feature 580, option KV.
Pressure instruments with a flange and threaded boss that do not have a pressurized housing do not
fall within the scope of the Pressure Equipment Directive, irrespective of the maximum allowable
pressure.
Levelflex FMP51 Modbus
A0029561
Endress+Hauser
