Levelflex FMP51 Modbus
R
ø4 (0.16)
Endress+Hauser
FMP51: Dimensions of process connection (G¾,NPT¾) and probe
E F
SW7
AF7
ø4 (0.16)
M14
ø22 (0.87)
 18 FMP51: Process connection / probe; dimensions: mm (in). Unit of measurement mm (in)
B Thread ISO G3/4 or ANSI MNPT3/4 (Feature (100)
E Rope probe 4mm or 1/6" (Feature 060)
F Rope probe 4 mm or 1/6"; centering disk optional (Features 060 and 610)
G Rod probe 8mm or 1/3" (Feature 060)
H Coax probe (Feature 060); with venting hole Ø approx. 6 mm (0.24 in)
LN Length of probe
R Reference point of the measurement
B
SW36
AF36
G¾
NPT¾
G
SW7
SW7
AF7
AF7
ø8 (0.31)
ø29.5 (1.16)
ø75 (2.95)
H
ø22 (0.87)
2 (0.08)
8 (0.31)
A0012645
