Pnp/Pci Configuration Option - Elitegroup Computer Systems K7S5A2 Manual

K7S5A2 V1.0
Power Up by Alarm (Disabled)
When set to Enabled, the following three fields become avail-
able: Month Alarm, Day of Month Alarm, and Time Alarm
Upon arrival of the alarm time, it will instruct the system to
wake up. When set to 0 (zero) for the day of the month, the
alarm will power on your system every day at the specified
time.

PNP/PCI Configuration Option

This option displays a table of items that configures how PnP
(Plug and Play) and PCI expansion cards operate in your sys-
tem. Both the ISA and PCI buses on the Mainboard use
system IRQs (Interrupt ReQuests) and DMAs (Direct Memory
Access). You must set up the IRQ and DMA assignments cor-
rectly through the PnP/PCI Configurations Setup utility;
otherwise, the mainboard will not work properly. Selecting
PnP/PCI Configurations on the main program screen displays
this menu:
CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software
Reset Configuration Data
Resources Controlled by
x IRQ Resources
PCI/VGA Palette Snoop
INT Pin 1 Assignment
INT Pin 2 Assignment
INT Pin 3 Assignment
INT Pin 4 Assignment
↑ ↓ → ← : Move Enter : Select
F5:Previous Values
Reset Configuration Data (Disabled)
If you enable this item and restart the system, any Plug and
Play configuration data stored in the BIOS setup is cleared
from memory. New updated data is created.
Resources Controlled By (Auto(ESCD))
You should leave this item at the default Auto(ESCD). Under
this setting, the system dynamically allocates resources to
PnP/PCI Configurations
[Disabled ]
[Auto(ESCD)]
Press Enter
[Disabled]
[Auto]
[Auto]
[Auto]
[Auto]
+/-/PU/PD:Value: F10: Save ESC: Exit
F6:Fail-Safe Defaults
57
Item Help
Menu Level
Default is Disabled.
Select Enabled to reset
Extended System Con-
figuration Data (ESCD)
when you exit Setup if you
have installed a new add-
on and the system recon-
figuration has caused
such a serious conflict
that the OS cannot boot
F1:General Help
F7:Optimized Defaults
