PNP/PCI Configuration Option

This option configures how PnP (Plug and Play) and PCI ex-
pansion cards operate in your system. Both the ISA and PCI
buses on the Mainboard use system IRQs (Interrupt Re-
Quests) and DMAs (Direct Memory Access). You must set up
the IRQ and DMA assignments correctly through the PnP/PCI
Configurations Setup utility for the mainboard to work properly.
Selecting PnP/PCI Configurations on the main program
screen displays this menu:
CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software
Reset Configuration Data
Resources Controlled by
x IRQ Resources
PCI/VGA Palette Snoop
INT Pin1 Assignment
INT Pin2 Assignment
INT Pin3 Assignment
INT Pin4 Assignment
INT Pin5 Assignment
INT Pin6 Assignment
INT Pin7 Assignment
INT Pin8 Assignment
↑ ↓ → ← : Move Enter : Select
F5:Previous Values
Reset Configuration Data (Disabled)
If you enable this item and restart the system, any Plug and
Play configuration data stored in the BIOS Setup is cleared
from memory.
Resources Controlled By (Auto(ESCD))
You should leave this item at the default Auto(ESCD). Under
this setting, the system dynamically allocates resources to
Plug and Play devices as they are required.
If you cannot get a legacy ISA (Industry Standard Architecture)
expansion card to work properly, you might be able to solve
the problem by changing this item to Manual, and then open-
ing up the IRQ Resources and Memory Resources submenus.
PnP/PCI Configurations
[Disabled]
[Auto(ESCD)]
[Press Enter]
[Disabled]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
+/-/PU/PD:Value: F10: Save ESC: Exit
F6:Fail-Safe Defaults
53
Item Help
Menu Level
Default is Disabled. Select
Enabled to reset Extended
System Configuration
Data (ESCD) when you
exit Setup if you have
installed a new add-on
and the system reconfigu-
ration has caused such a
serious conflict that the
OS cannot boot.
F1:General Help
F7:Optimized Defaults
