PCI Health Status Option
On mainboards that support hardware monitoring, this item
lets you monitor the parameters for critical voltages, critical
temperatures, and fan speeds. You cannot make any changes
to these fields. They are display only:
CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software
Shutdown Temperature
CPU Core Voltage
Vcc 2.5V
Vcc 3.3V
Vcc 5.0V
+12V
StandBy 3.3V
StandBy 5.0V
Voltage Battery
System Temperature
CPU Temperature
CPU FAN speed
PWR Fan1 Speed
PWR Fan2 Speed
↑ ↓ → ← : MoveEnter : Select
F5:Previous Values
Shutdown Temperature
Enables you to set the maximum temperature the system can
reach before powering down.
System Component Characteristics
These fields provide you with information about the systems
current operating status. You cannot make changes to these
fields.
PC Health Status
[Disabled ]
+/-/PU/PD:Value: F10: Save ESC: Exit F1:General Help
F6:Fail-Safe Defaults F7:Optimized Defaults
