K7S5A2 V1.0
AC97 ACCESS INTERFACE (Embedded BUS)
This option determines whether the AC97 interface uses an
embedded bus or a PCI bus
Press <Esc> to return to the Integrated Peripherals screen.
Onboard SuperIO Device
Scroll to this item and press <Enter> to view the following
screen:
CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software
Onboard FDC Controller
Onboard Serial Port 1
Onboard Serial Port 2
UART Mode Select
UR2 Duplex Mode
Onboard Parallel Port
Parallel Port Mode
ECP Mode Use DMA
Game Port Address
Midi Port Address
Midi Port IRQ
↑ ↓ → ← : Move Enter : Select
F5:Previous Values
Onboard FDC Controller (Enabled)
This option enables the onboard floppy disk drive controller.
Onboard Serial Port 1 (3F8/IRQ4)
This option is used to assign the I/O address and interrupt re-
quest (IRQ) for onboard serial port 1 (COM1).
Onboard Serial Port 2 (2F8/IRQ3)
This option is used to assign the I/O address and interrupt re-
quest (IRQ) for onboard serial port 2 (COM2).
UART Mode Select (Normal)
This field is available if the Onboard Serial Port 2 field is set to
any option but Disabled. UART Mode Select enables you to
select the infrared communication protocol-Normal (default),
IrDA, or ASKIR. IrDA is an infrared communication protocol
with a maximum baud rate up to 115.2K bps. ASKIR is
Sharp's infrared communication protocol with a maximum
Onboard SuperIO Device
[Enabled]
[3F8/IRQ4]
[2F8/IRQ3]
[Normal]
[Half]
[378/IRQ7]
[ECP]
[3]
[201]
[330]
[10]
+/-/PU/PD:Value: F10: Save ESC: Exit
F6:Fail-Safe Defaults
50
Item Help
Menu Level
F1:General Help
F7:Optimized Defaults
