K7S5A2 V1.0
PM Wake Up Events
Scroll to this item and press <Enter> to view the following
screen:
CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software
IRQ [3-7, 9-15], NMI
IRQ 8 Break suspend
Ring Power Up Control
PCIPME Power Up Control
KB Power ON Password
Power Up by Alarm
x Month Alarm
x Date (of Month)
x Time (hh:mm:ss)
↑ ↓ → ← : Move Enter : Select
F5:Previous Values
This item opens a submenu that enables you to set events
that will resume the system from a power saving mode.
IRQ [3-7, 9-15], NMI (Enabled)
This option determines whether any activity for IRQ 3 -7/9-15
will cause the system to wake from a power saving mode.
IRQ 8 Break Suspend
Determines whether the system will monitor IRQ 8 activity and
wake the system from a power saving mode when IRQ 8 is
activated.
Ring Power Up Control (Disabled)
Use this item to enable LAN or modem activity to wakeup the
system from a power saving mode.
PCIPME Power Up Control (Enabled)
Use this item to enable PCI activity to wakeup the system
from a power saving mode.
KB Power ON Password (Enter)
Allows you to set the KB Power ON password.
PM Wake Up Events
[Enabled ]
[Disabled]
[Enabled]
[Enabled]
[Enter]
[Disabled]
NA
0
0 0 0
+/-/PU/PD:Value: F10: Save ESC: Exit
F6:Fail-Safe Defaults F7:Optimized Defaults
56
Item Help
Menu Level
F1:General Help
