USB2/USB3: Internal USB connectors
The mainboard has two USB ports installed on the rear edge
I/O port array. However, some computer cases have a special
module that mounts USB ports at the front of the case. If you
have this kind of case, use the auxiliary USB connectors
USB2 and USB3 to connect the front-mounted ports to the
mainboard.
Pin Signal Name
1 USBPWR0
3 USB_FP_P0-
5 USB_FP_P0+
7 GND
9 KEY
WOL1/WOM: Wake On LAN/Wake On Modem
If you have installed a LAN card, use the cable provided with
the card to plug into the mainboard WOL1 connector. This en-
ables the Wake On LAN (WOL) feature. When your system is
in a power-saving mode, any LAN signal automatically re-
sumes the system. You must enable this item using the Power
Management page of the Setup Utility.
Pin Signal Name
1 5VSB
2 Ground
3 SENSE
If you have installed a modem, use the cable provided with
the modem to plug into the mainboard WOM1 connector. This
enables the Wake On Modem (WOM) feature. When your sys-
tem is in a power-saving mode, any modem signal
automatically resumes the system. You must enable this item
using the Power Management page of the Setup Utility. See
Chapter 3 for more information.
Pin Signal Name
2 USBPWR1
4 USB_FP_P1-
6 USB_FP_P1+
8 GND
10 USB_FP_OC0
