K7S5A2 V1.0
SIS OnChip IDE Device
Scroll to this item and press <Enter> to view the following
screen:
CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software
Internal PCI/IDE
Primary Master PIO
Primary Slave PIO
Secondary Master PIO
Secondary Slave PIO
Primary Master UltraDMA [Auto]
Primary Slave UltraDMA [Auto]
Secondary Master UltraDMA [Auto]
Secondary Slave UltraDMA [Auto]
IDE Burst Mode
↑ ↓ → ← : Move Enter : Select
F5:Previous Values
Internal PCI/IDE (Both)
Use these items to enable or disable the internal PCI IDE
channels that are integrated on the mainboard.
IDE Primary/Secondary Master/Slave PIO (Auto)
Each IDE channel supports a master device and a slave de-
vice. These four items let you assign which kind of PIO
(Programmed Input/Output) is used by IDE devices. Choose
Auto to let the system auto detect which PIO mode is best, or
select a PIO mode from 0-4.
IDE Primary/Secondary Master/Slave UltraDMA (Auto)
Each IDE channel supports a master device and a slave de-
vice. This mainboard supports UltraDMA technology, which
provides faster access to IDE devices.
If you install a device that supports UltraDMA, change the ap-
propriate item on this list to Auto. You may have to install the
UltraDMA driver supplied with this mainboard in order to use
an UltraDMA device.
IDE Burst Mode (Enabled)
This option, when enabled will instruct the system to send
every write transaction to the write buffer. Burstable transac-
SIS OnChip IDE Device
[Both]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
+/-/PU/PD:Value: F10: Save ESC: Exit
F6:Fail-Safe Defaults
48
Item Help
Menu Level
F1:General Help
F7:Optimized Defaults
