K7S5A2 V1.0
Advanced DRAM Control 1
Scroll to this item and press <Enter> to view the following
screen:
CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software
Auto configuration
CPU/DRAM CLK Synch CTL
DRAM BackGround Cycles
LD-Off Dram RD/WR Cycles
↑ ↓ → ← : Move Enter : Select
F5:Previous Values
Auto Configuration (Normal Mode)
This is the DRAM auto configuration option, which can be set
to Safe Mode, Normal Mode, Fast Mode or Ultra Mode.
CPU/DRAM CLK Synch CTL (AUTO)
This option allows you set the CPU/DRAM synchronization.
The valid options are AUTO, Synchronous, and Asynchronous.
DRAM BackGround Cycles (Delay 1T)
This option allows you to set the DRAM background cycles.
The valid options are AUTO, Delay 1T, and Normal.
LD-Off Dram RD/WR cycles (Delay 1T)
This option allows you to set the LD-Off DRAM RD/WR cycles.
Valid values are AUTO, Delay 1T, and Normal.
Advanced DRAM Control 1
[Normal Mode]
[AUTO]
[Delay 1T]
[Delay 1T]
+/-/PU/PD:Value: F10: Save ESC: Exit
F6:Fail-Safe Defaults
45
Item Help
Menu Level
F1:General Help
F7:Optimized Defaults
