Operating Instructions and Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or
maintain the product described. Protect yourself and others by observing all safety information. Failure to
comply with instructions could result in personal injury and/or property damage! Retain instructions for
future reference.
Description
This pump is a high capacity, self-
priming centrifugal pump suitable for
lawn sprinkling or other applications
where large quantities of water are
required. Flammable liquids such as
gasoline, chemicals or corrosive liquids
should never be used with this pump.
Safety Guidelines
This manual contains information that
is very important to know and
understand. This information is
provided for SAFETY and to
PREVENT EQUIPMENT PROBLEMS. To
help recognize this information,
observe the following symbols.
Danger indicates
an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
Warning indicates
a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
Caution indicates a
potentially hazardous
situation which, if not avoided, may result
in minor or moderate injury.
Notice indicates
important
information, that if not followed, may
cause damage to equipment.
General Safety
Information
CALIFORNIA PROPOSITION 65
This product or its
power cord may
contain chemicals, including lead, known
to the State of California to cause cancer
and birth defects or other reproductive
harm. Wash hands after handling.
GENERAL SAFETY INFORMATION
1. Read these rules and
instructions carefully. Failure
to follow these instuctions
could cause serious bodily
injury and/or property damage.
© 2009 Wayne Water Systems
Lawn Sprinkler
Pump
only clear water. Do not pump
flammable or explosive fluids
such as gasoline, fuel oil,
kerosene, etc. Do not use in a flammable
and/or explosive atmosphere. Personal
injury and/or property damage could result.
salt water, brine, laundry discharge or
any other application which may
contain caustic chemicals and/or foreign
materials. Pump damage could occur if
used in these applications and will void
warranty.
All wiring must be
performed by a qualified
electrician. The pump must
be installed in compliance with all local
and national codes.
2. Connect this product to a grounded
circuit equipped with a ground fault
interruptor device.
3. Before installing this product, have
the electrical circuit checked by an
electrician to ensure proper
grounding.
4. BE CERTAIN the pump
power source is
disconnected before
installing or servicing
pump.
5. Check motor voltage setting on
motor end plate and make sure the
line voltage of the electrical current
supply is correct.
6. Be sure the water source and piping
is clear of sand, dirt and scale.
Debris will clog pump and void
warranty.
7. Failure to protect pump and piping
from freezing could cause severe
MANUAL
damage and will void the warranty.
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.waynepumps.com
This pump is non- 8. Do not run pump dry. Follow
submersible.
priming instructions.
Installation
Pump
Protect pump from the elements by
installing in a basement, garage, tool
shed or pump house. Install the pump
so the center line of the pump is as close
as possible to the water level. Keep
This pump is not installation area clear to provide access
designed to handle
for service and maintenance. Protect the
pump against flooding and excess
moisture.
Make sure the pump has adequate
ventilation. The surrounding
temperature should not exceed 100°F
(38°C) or nuisance tripping of the motor
may occur.
PUMP PIPING INSTALLATION
Use new pipe for best results.
Galvanized or plastic pipe can be used.
When using galvanized pipe, provide
independent supports for both suction
and discharge piping near the pump to
avoid strain on the pump. Minimize use
of elbows and fittings to reduce friction
loss. Refer to the friction loss chart for
specific information.
Increase diameter of suction or discharge
piping if length is over 50 feet.
SUCTION PIPING
over intake of suction piping.
Never use pipe smaller than 2" in
diameter for suction piping. The suction
pipe must be kept free of air leaks. For
horizontal runs, lay pipe from the water
source so the upward slope is at least 1/2"
per foot. This eliminates trapped air. The
threaded inlet of the pump is 2" NPT.
swimming areas.
WLS75, WLS100
WLS150, WLS200
Install foot valve
or strainer screen
Do not install suc-
tion piping near
320201-001 4/09
