Operating Instructions and Parts Manual
SPECIFICATIONS
POWER SUPPLY REQUIREMENT
MOTOR
HORSEPOWER
CIRCUIT REQUIREMENT
LIQUID TEMPERATURE RANGE
© 2018, WAYNE/Scott Fetzer Company
Please read and save these instructions. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in personal injury and/or property
damage! Retain instructions for future reference.
120 V or 230 V, 60 Hz (WLS150)
230 V, 60 Hz (WLS200)
Single Phase, Continuous Duty
1 1/2 HP............... (WLS150)
2 HP ................... (WLS200)
15 A (minimum)
40° F- 120° F
PERFORMANCE
Model
PSI Discharge Head
15
Gal / hr
20
Gal / hr
WLS150
25
Gal / hr
30
Gal / hr
15
Gal / hr
20
Gal / hr
WLS200
25
Gal / hr
30
Gal / hr
Intended for Indoor Use Only
CONSTRUCTION
MOTOR HOUSING
MOTOR SHAFT
IMPELLER
VOLUTE
PUMP SUCTION
PUMP DISCHARGE
5 ft
10 ft
15 ft
20 ft
4350
4200
3950
3700
3950
3700
3450
3250
3400
3200
3000
2800
2950
2750
2500
2150
-
-
5300
5150
5300
5100
4850
4550
4800
4500
4250
4000
4200
3950
3750
3450
www.waynepumps.com
Lawn Sprinkler Pump
WLS Series
Coated Steel
Stainless Steel
Thermoplastic
Cast Iron
2 in. NPT
1-1/2 in. NPT
25 ft
3500
3050
2500
1700
4850
4300
3750
3100
650002-001 B 08/18
Advertisement
Table of Contents
Related Manuals for Wayne WLS150
Summary of Contents for Wayne WLS150
- Page 1 Operating Instructions and Parts Manual WLS Series CONSTRUCTION SPECIFICATIONS MOTOR HOUSING Coated Steel POWER SUPPLY REQUIREMENT 120 V or 230 V, 60 Hz (WLS150) MOTOR SHAFT Stainless Steel 230 V, 60 Hz (WLS200) MOTOR Single Phase, Continuous Duty IMPELLER Thermoplastic HORSEPOWER 1 1/2 HP....
-
Page 2: General Safety Information
Operating Instructions and Parts Manual GENERAL SAFETY INFORMATION DESCRIPTION This pump is a high capacity, centrifugal pump suitable for lawn CALIFORNIA PROPOSITION 65 sprinkling or other applications where large quantities of water are required. UNPACKING This product can expose you to chemicals, including DEHP, Inspect this unit before it is used. - Page 3 Operating Instructions and Parts Manual WLS Series www.waynepumps.com...
-
Page 4: Pump Piping Installation
Operating Instructions and Parts Manual GENERAL SAFETY INFORMATION (CONT’D) INSTALLATION All wiring must be performed by a qualified Protect pump from the elements by installing electrician. The pump must be installed in compliance with in a basement, garage, tool shed or pump house. Install the pump so all local and national codes. - Page 5 Operating Instructions and Parts Manual WLS Series CONNECTION TO WATER SOURCE DRILLED WELL INSTALLATION Install a foot valve on the first section of pipe (see Figure 2). PIPE PLUG TO SPRAY Lower the pipe into the well. NOZZLES Add pipe until the foot valve is 10 feet below the lowest anticipated 1-1/2”...
- Page 6 Operating Instructions and Parts Manual DRIVEN WELL INSTALLATION DUG WELL, CISTERN, LAKE AND SPRING INSTALLATION • Drive the point several feet below the water table. NOTE: A packer-type foot valve can be installed in the well (See Figure • Install a foot valve on the inlet pipe and lower into the water. 3).
-
Page 7: Electrical Connections
The voltage of power supply must match the voltage of the pump. The WLS150 has a dual voltage motor preset at the factory to 230 volts. The Le couvercle de bornes doit être en place et motor can be converted to 115 volts by changing the voltage selector fermé... -
Page 8: Operation
Operating Instructions and Parts Manual Remove the square cut gasket from the seal plate and discard. OPERATION Remove the three screws from the diffuser assembly, and then remove the diffuser from the seal plate. The intake on the diffuser Never run the pump dry. Running pump without has an O-Ring seal and is covered with a lubricant, remove the water may cause seal damage. -
Page 9: Troubleshooting Chart
Operating Instructions and Parts Manual WLS Series TROUBLESHOOTING CHART Symptom Possible Cause(s) Corrective Action Motor will not run 1. Disconnect switch is off 1. Be sure switch is on 2. Fuse is blown or circuit breaker tripped 2. Replace fuse 3. -
Page 10: Replacement Parts List
1, 2 1, 2 REPLACEMENT PARTS LIST Ref. Description Part Number Qty. 62063-WYN1 WLS200, 2 HP Kit - Square Ring, Impeller, Diffuser, Screws, Shaft Seal Assembly 62064-WYN1 WLS150, 1.5 HP Kit - Square Ring, Impeller, Diffuser, Screws, Shaft Seal Assembly www.waynepumps.com... -
Page 11: Limited Warranty
LIMITED WARRANTY For one year for WLS Series models from the date of purchase, from an authorized dealer, Wayne Water Systems will repair or replace, at its option for the original purchaser, any part or parts of its Lawn Pumps or Water Pumps (“Product”) found upon examination by Wayne Water Systems to be defective in materials or workmanship. - Page 12 NOTES www.waynepumps.com...
