1.2.6 Energy consumption

Type of drive:
Type of oil:
Maximum operating pressure
at continuous load:
Hydraulic connections:
The Gigant sweeping machine requires
N O T E
single-acting and/or double-acting control
circuits from the carrier vehicle hydraulics.
The quantity and type the required control
circuits depends on the equipment of the
Gigant sweeping machine.
For further details on energy consumption,
N O T E
refer to Chapter 1.2.8 Technical data

1.2.7 Intended usage

The Gigant sweeping machine is a machine that is set in
motion via a hydraulic circuit and through the attachment
to a suitable carrier vehicle. Its purpose is to clean irm
surfaces with normal dirt build-up.
If the machine is used for a purpose different from the
one above, we, as the manufacturer, do not take any
responsibility for the safety; the risk in this respect rests
entirely with the user.
Proper usage includes observance of the operating,
maintenance and service conditions that we prescribe
as well as relevant speciications.
hydraulic
hydraulic oil according to
ISO VG 46 DIN 51524
(e.g., Vitam GF 46 by Aral)
175 bar
see adjacent table
SA = single acting
control circuit
DA = double acting
control circuit
• Open sweeping
• Hydraulic drive
• Electro-hydr. side
adjustment
• Open sweeping
• Hydraulic drive
• Mech. side adjustment
• Open sweeping
• Hydraulic drive
• Hydr. side adjustment
• Dirt collection vessel
• Hydraulic drive
• Mech. side adjustment
• Side broom
• Dirt collection vessel
• Hydraulic drive
• Hydr. side adjustment
• Side broom
• Dirt collection vessel
• Hydraulic drive
• Electro-hydr. side
adjustment
• Side broom
General
1 x
DA
1 x
SA
1 x
SA
+
1 x
DA
1 x
DA
2 x
DA
1 x
DA
