Technical Data Sheet - Tuchel Profi Gigant Operating Manual

General

1.2.8 Technical data sheet

Proi - Gigant technical data
Operating width / A = total width
B = Operating width if positioned at an angle of 20° mm
Weight of basic machine
Weight of basic machine + collector vessel
Dirt collection vessel volume
∅Sweeping drum/side broom
Oil quantity required (at 160 bar)
Maximum operating pressure at continuous load
Use the weights to check compliance with the
maximum allowed axle load of the carrier vehicle!
Weights are approximate values and vary
N O T E
depending on the machine coniguration,
receptacle not included.
10
Receptacle
Aufnahme
2822
1819
590
311
Unit 260 290
2600/2860 2900/3250 3200/3550 3500/3850
mm
2360 2630
kg
1200 1250
kg
1650 1700
kg
760 850
800/550 800/550
mm
l/min
bar
N O T E
B
A
320 350
2900 3170
1300 1350
1760 1820
935 1025
800/550 800/550
100
175
We reserve the
right to incorporate
changes resulting
from further technical
development.
