OAKWORKS ProLuxe Series User Manual

With optional adjustable side arm rests and universal table extender/with optional adjustable side arm rests and universal table extender/with optional quicklock face rest and boiance crescent
Hide thumbs Also See for ProLuxe Series:

Advertisement

Quick Links

USER MANUAL
Electric Salon Top
Shown with optional
Adjustable Side Arm Rests
and Universal Table Extender
Lift Assist Salon Top
Shown with optional
Adjustable Side Arm Rests
and Universal Table Extender
www.OAKWORKS.com · 717.235.6807
ProLuxe
Series
Lift Assist Backrest Top
Flat Top
Shown with optional QuickLock™ Face
Rest and Boiance crescent
made in the USA
with US & imported parts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLuxe Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for OAKWORKS ProLuxe Series

  • Page 1 Lift Assist Salon Top Lift Assist Backrest Top Flat Top Shown with optional Shown with optional QuickLock™ Face Adjustable Side Arm Rests Rest and Boiance crescent and Universal Table Extender made in the USA with US & imported parts www.OAKWORKS.com · 717.235.6807...
  • Page 2 ® damages in connection with or arising out of the furnishing, performance, or OAKWORKS is a registered use of this document and the program ® trademark of OAKWORKS , Inc. material which it describes. ®...
  • Page 3: Table Of Contents

    Cleaning & Disinfection Recommended Cleaners/Disinfectants ..................18 Cleaning Process ..........................19 Inspections & Maintenance ........................19 Warranty Information ..........................19 Model Number & Serial Number Proluxe Series .............................20 Specifications Product Specifications ........................21 Environmental Conditions ......................21 Electrical Specifications ........................21 Guidance and manufacturer’s declaration - Electromagnetic emissions ......................22 Recommended separation distances ...................22...
  • Page 4: Product Use Description

    There are no known contraindications to the use of this equipment. The ProLuxe Series should not be used in any other manner than that described within this manual. Use of any unnecessary force or unauthorized procedures could result in injury to practitioner, client or equipment.
  • Page 5 2. Unplug from outlet before adding or removing parts. 3. Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Contact Oakworks Customer Service before use at 717.235.6807.
  • Page 6: Product Description & Photo

    PRODUCT DESCRIPTION Proluxe Flat Top Upholstered Top QuickLock™ Face rest with Boiance™ Crescent Self-locking molded rubber feet (2) Accessory attachment outlets Steel Scissor-style powder-coated base with dual crossbeams (1) Wheels (2) Foot Control STANDARD SPECIFICATIONS Height Range Powered 18”-35” (46-89 cm.) Based on 3” 3”...
  • Page 7: Proluxe™ Lift Assist Backrest Top

    PRODUCT DESCRIPTION Proluxe Lift-Assist Backrest Top Manual Lift-Assist Back Rest control Upholstered Top Self-locking molded rubber Accessory attachment feet (2) outlets Steel Scissor-style powder-coated base with dual crossbeams (1) Wheels (2) Foot Control STANDARD SPECIFICATIONS Motion 1 Powered 21”-38” (55-97 cm.) Height Range 3”...
  • Page 8: Proluxe™ Lift Assist Salon Top

    PRODUCT DESCRIPTION Proluxe Lift-Assist Salon Top Table Extender (accessory) Adjustable Arm Rests (2) (accessory) Upholstered Top Manual Lift-Assist Back Rest control Self-locking molded rubber feet (2) Accessory attachment outlets Steel Scissor-style Wheels (2) powder-coated base with dual crossbeams (1) Foot Control STANDARD SPECIFICATIONS Motion 1 Powered 21”-38”...
  • Page 9: Proluxe™ Electric Salon Top

    PRODUCT DESCRIPTION Proluxe Electric Salon Top Table Extender (accessory) Adjustable Arm Rests (2) (accessory) Upholstered Top Self-locking molded rubber feet (2) Steel Scissor-style Accessory attachment powder-coated base outlets with dual crossbeams (1) Wheels (2) Multi-function Foot Control STANDARD SPECIFICATIONS Motion 1 Powered 21”-38”...
  • Page 10: Installation

    INSTALLATION The Tables come completely assembled and ready to use. Plug the cord into a functioning outlet that is rated for the table. (see Grounding below) Arrange the power cord and control cords so that they will not create a tripping hazard and where the controls are located to your liking and are conveniently accessible.
  • Page 11: Directions For Use

    DIRECTIONS FOR USE CONTROL OPERATIONS - FLAT TOP, LIFT-ASSIST BACKREST AND SALON TABLES ONLY CAUTION Be sure the self-locking molded rubber feet are flat side down to ensure safety and stability. The tables offer height positioning with electronic ease. Operate the Foot control and Optional Hand Control as shown below to raise or lower the height of the table.
  • Page 12: Foot Control Operations - Electric Salon Tables Only

    DIRECTIONS FOR USE FOOT CONTROL OPERATIONS - ELECTRIC SALON TABLES ONLY CAUTION Do not sit on the backrest or leg rest sections. Be sure the self-locking molded rubber feet are flat side down to ensure safety and stability. The hood area under the backrest top is not designed for stor- age.
  • Page 13: Hand Control Operations - Electric Salon Tables Only

    DIRECTIONS FOR USE HAND CONTROL OPERATIONS - ELECTRIC SALON TABLES ONLY CAUTION Do not sit backrest or leg rest sections. Be sure the self-locking molded rubber feet are flat side down to ensure safety and stability. The hood area under the backrest top is not designed for storage. Do not use this area for holding anything.
  • Page 14: Hand Control Operations - Adjustable Breast Comfort (Abc) Systems Only

    DIRECTIONS FOR USE HAND CONTROL OPERATIONS - ADJUSTABLE BREAST COMFORT (ABC) SYSTEMS ONLY CAUTION ABC System Weight Limit - 100 lbs. (45 kg.) Do not place foreign objects into the ABC System. Only use as intended. For safety of your client, use a cloth sheet between the ABC System and your client.
  • Page 15: Adjusting The Back Rest Section

    DIRECTIONS FOR USE ADJUSTING THE BACK REST SECTION CAUTION Do not sit on the Back Rest section. Back Rest Control TO RAISE THE BACK REST TO LOWER THE BACK REST: TO CHANGE LEVER POSITION: Raise the back rest by pressing the lever Press the lever under the head section and The back rest lever can be moved to the under the head section and lifting up to the...
  • Page 16: Moving The Table

    DIRECTIONS FOR USE MOVING THE TABLE Before moving any of the Tables, disconnect the power cord from the power outlet. The CAUTION table weighs as much as 200 lbs. (91 kg.) Use extreme caution when lifting the table to move it. Two people are required to move the table safely. DO NOT use the table to transport a patient.
  • Page 17: Hot Towel Cabi & Storage Shelf

    DIRECTIONS FOR USE HOT TOWEL CABI SHELF & STORAGE SHELF The Anti-Tip Strap must be installed when using a Hot Towel Cabi. CAUTION Do not overload the storage Shelf. [Max load weight is 25 lbs. (11.3 kg)] Anti-Tip Strap The Cabi Shelf holds a Hot Towel Cabi The Power Strip will power the Hot The Storage Shelf provides storage for with dimensions no greater than 17.9”...
  • Page 18: Adjustable Arm Rest Installation And Adjustment

    DIRECTIONS FOR USE ADJUSTABLE ARM REST INSTALLATION AND ADJUSTMENT Do not use the arm rest for patient support during the mounting or dismounting of the chair. CAUTION The arm rest is not designed to support the patient’s weight. TO INSTALL THE ARM RESTS: The Arm Rests adjust automatically as the back rest moves to remain parallel to the floor.
  • Page 19: Adjustable Breast Comfort (Abc) System Use

    DIRECTIONS FOR USE ADJUSTABLE BREAST COMFORT (ABC) SYSTEM USE ABC System Weight Limit - 100 lbs. (45 kg.) Do not sit on the ABC System. Do not place CAUTION foreign objects into the ABC System. Only use as intended. For safety of your client, use a cloth sheet between the ABC System and your client.
  • Page 20 DIRECTIONS FOR USE ADJUSTABLE BREAST COMFORT (ABC) SYSTEM USE CONTD... CLEANING THE ABC SYSTEM: If cleaning inside the ABC system is desired, remove the 6 Phillips Head screws with a Phillips head screwdriver. Remove the ABC cover and wipe down the inside of the system. When finished, reattach the cover with the 6 screws.
  • Page 21: Cleaning & Disinfection

    To reduce the risk of electric shock: DANGER - Always unplug this furnishing from the electrical outlet before cleaning. The following cleaners were tested by OAKWORKS ® and found to be acceptably compatible with all materials used in construction of our tables: Formula 409 ®...
  • Page 22: Cleaning Process

    - Always unplug this furnishing form the electrical outlet before cleaning. ® Follow the cleaners/disinfectant manufacturers’ directions for use. Please note that cleaning and disinfecting an OAKWORKS table is a two part process. First it must be cleaned of any visible soil, then it can be disinfected. The table should be cleaned as soon as possible after use.
  • Page 23: Model Number & Serial Number

    MODEL NUMBER & SERIAL NUMBER PROLUXE SERIES The model number and serial number are located on the underside of the foot section. Serial Number Model Number 16796025 PXEXFT311873ACTTVN Ser#:PXR563146 PX FT 30 x 22-38 x 72 3M/TT/2S TTSKYBLUE 01/04/2013 Order#:654321 Notes: Sample Product Label Model Numbers and Serial Numbers always start with a letter.
  • Page 24: Specifications

    SPECIFICATIONS PRODUCT SPECIFICATIONS Table Weights: 151-202 lbs. (68-92 kg.) Shipping Weights: 236-287 lbs. (107-130 kg.) Lifting Capacity 550 lbs. (250 kg.) ENVIRONMENTAL CONDITIONS Conditions Temperature Humidity Atmospheric Pressure Normal Use 50° (10°C) to 104° (40°C) 20% to 60% RH 98 to 105 kPa Storage &...
  • Page 25: Guidance And Manufacturer's Declaration - Electromagnetic Emissions

    SPECIFICATIONS Guidance and manufacturer’s declaration - electromagnetic emissions The table is intended for use in the electromagnetic environment specified below. The customer or the user of the table should assure that it is used in such an environment. Emissions Test Compliance Electromagnetic environment - guidance The table uses RF energy only for its internal...
  • Page 26: Guidance And Manufacturer's Declaration - Electromagnetic Immunity

    SPECIFICATIONS Guidance and manufacturer’s declaration - electromagnetic immunity The table is intended for use in the electromagnetic environment specified below. The customer or the user of the table should assure that it is used in such an environment. Electromagnetic Immunity Test IEC 60601 test level Compliance level environment - guidance...
  • Page 27 SPECIFICATIONS Guidance and manufacturer’s declaration - electromagnetic immunity The table is intended for use in the electromagnetic environment specified below. The customer or the user of the table should assure that it is used in such an environment. Electromagnetic Immunity Test IEC 60601 test level Compliance level environment - guidance...
  • Page 28: Contact Information

    Inc. ® AKWORKS 923 East Wellspring Road New Freedom, PA 17349 Phone: 717-235-6807 FAX: 717-235-6798 www.oakworks.com 3034177 CONFORMS TO: ANSI/AAMI STD ES60601-1 IEC STD 60601-1 3RD EDITION IEC STD 60601-1-2 3RD EDITION IEC STD 60601-1-6 3RD EDITION CERTIFIED TO CAN/CSA STD C22.2 NO. 60601-1...
