3.2

Setting up / installing the grease separator

When full, the grease separator is heavy. Ensure an adequately load-bearing surface for installation (see chapter 5.3 on
page 27).
• Install the grease separator on a level surface with adequate load-bearing capacity.
Drillholes for attachments and pipes
drillhole edges when passage seals are planned. We recommend use of the KESSEL hole saw Art. No. 500101 (Ø
121 mm). Always follow the enclosed instructions.
Torques for the screw connections
3.3

Connect the inlet and outlet

• Make pipe connections to the building installation at inlet <1> and
outlet <2>.
010-296
(system version Direct) are to be made using a hole saw. Do not deburr the
are listed in chapter 5.1. Make sure these are heeded accordingly.
22 / 88
1
Fig. [2]
2
