16.3 - Next we'll get the 3 Cheapskate bearings built. For this step you'll need the package of #6-
32, 2" machine screws, the #6 washers, the #6-32 x 1.75" cap head screws, the bag of #6-32 Nylon lock-
nuts, #4-40 x 1/2" socket head cap screws, #4 washers and #4 T-Nuts. Make sure when assembling the
Cheapskate that the text on the faces of the Melamine or Acrylic parts face the same direction. Note
that it may be easier to install the #4-40 T-Nuts for the next step at this stage. If you're using Acrylic,
you'll want to flatten the prongs on the T-Nuts. Insert two #6-32 machine screws with #6 washers in the
holes marked "SPACER" and install spacers on the other side.
16.4 - Install two bearings on to the spacers
Rostock Max Assembly Guide
Figure 60 - Bearing Spacers Installed.
Figure 61 - Bearings Installed.
