Setting Up your Receiver

The Smart-Vue Pro LoRaWAN enabled receiver is configured
using an integrated web interface. You must use that interface
to determine how your receiver connects to the internet, that
is, via an Ethernet or Wi-Fi. This chapter describes how to
connect to your receiver and enter the appropriate setting for
your solution.

Getting Started

Plug in the Smart-Vue Pro
LoRaWAN Antenna
1. Plug the white Smart-Vue Pro LoRaWAN radio antenna
into the "RF" connector (the location may vary according
to your unit's options).
2. Hand-tighten the antenna by rotating the ring clockwise.
Figure 3. Attach Smart-Vue Pro LoRaWAN Antenna
to connector labeled "RF"
Smart-Vue Pro LoRaWAN Enabled Receiver
Plug in the Power Cable
1. Plug the power cable into the stainless-steel connector
behind the receiver. The cable fits correctly onto one of
the connectors.
2. Tighten the cable by rotating the steel ring clockwise to
attach it firmly to the unit.
Figure 4. Plug in the power cable to the
stainless steel connector
3. Plug the AC adapter into a power socket to boot the
receiver. The startup process may take 2-3 minutes to
complete. When the unit is ready for use, the left-hand
LED remains lit as shown here (the status LED continues
to blink):
Figure 5. Power indicator remains on when
receiver is ready to use
