Bar ON indicator NOT
illuminated
Fault indicator
illuminated
IQ Power BPS
No static bar connected
Static bar high voltage connector
is not connected
Static bar high voltage connector
missing bar type sense pin
Static bar mounted too close to
grounded metal
Damage to high voltage
connector
Damage to high voltage cable
Faulty HV module inside power
supply
26
Install static bar and connect to
power supply
Turn off power, reconnect static
bar and secure plug with captive
screws
Replace static bar high voltage
connector plug
Separate static bar from
grounded metal
Replace high voltage connector
Replace static bar
Replace high voltage module
5201249 Rev. D
