When the IQ Power BPS is first turned on it will illuminate all LED indicators as
a self-test. Then it will briefly display the IQ Power address in steadily lit indicators
using the OUTPUT bar graph LEDs. See the following table for interpreting the
address number.
Where a Control Station is used, the power supply address numbers may be
manually adjusted or may be automatically set by the Control Station. Having
multiple power supplies with the same address number connected to a Control
Station is not permitted.
To manually adjust the power supply address, turn the unit on and wait for the LED
self-test to complete. The COMM light will briefly stay lit and the power supply
number may be adjusted at this time. Press and hold the Calibrate button until the
power supply number increments by one (5 second window). Subsequent presses of
the Calibrate button will increment the power supply numbers (5 second window).
The IQ Power BPS Power Supply Number will "map" as shown on the Power
Supply Number (Address / Device Number) Table above. The incrementing "wraps
around". Stop pressing the Calibrate button when the desired power supply number
has been reached. Wait 5 seconds, the COMM light will go out and the Speed and
Distance LEDs will flicker, indicating the power supply address number has been
saved.
To automatically set the power supply address, use the Control Station. The default
Power Supply Number for a new unit is "1". Plug the first power supply (only) into
the Control Station and turn the Control Station on. Allow the Control Station
to boot-up and begin operation. Plug the second power supply into the Control
Station. The Control Station will re-address the second power supply to "2". Plug
the third power supply into the Control Station. The Control Station will re-address
the third power supply to "3". Repeat this process until all power supplies (or IQ
Power / IQ Easy devices) are installed. Each power supply or device will be given a
unique address (device number).
IQ Power BPS
Power Supply Number (Address / Device Number)
IQ Power Address
1 (default)
2
3
4
5
6
7
8
9
10
OUTPUT LED Illuminated
LOW (1)
2
3
4
5
6
7
8
9
(none)
16
