G. Install (2) set screws into the holes in the side of the mounting bracket using the
provided hex key wrench. The set screws engage the "T" on the base of the bar
securing it in place.
See Static Bar Installation and Static Bar Bracket diagrams.
Mounting the Power Supply
A. Locate power supply at a convenient place within reach of the static bar high
voltage cable (standard length 3m [10 ft]) and visible to the machine operator.
Power for the AC adapter and an electrical ground connection must be available.
B. Secure power supply to the mounting surface (commonly a machine frame)
using M5 or M4 [#10 or #8] hardware (not supplied).
C. Locate AC adapter (if used) at a convenient, secure place within reach of the
power supply.
NOTE – Do not apply line voltage to the AC adapter until installation is
complete. Also ensure that all input power switches are in the OFF (0)
position.
Electrical Connections
A. Ground power supply by connecting ground lead between ground terminal on
flange of the power supply and a good electrical machine ground.
B. Connect static bar(s) by plugging in high voltage connector on static bar to HV1
or HV2 on power supply. Secure high voltage connector with the (2) captive
screws on the sides of the connector. Do not over-tighten.
See Bar and BPS Power Supply Connections diagram.
CAUTION – Electrical Shock Hazard
Do not connect static neutralizing bar with power supply energized.
Disconnect input power or switch power off before connecting static bar.
NOTE – Failure to fully seat the high voltage connectors into the power
supply connectors may result in permanent damage to the bar, cable or
power supply.
The exposed pin on the connector "tells" the power supply what type of IQ Power
static bar is being connected and automatically sets up the power supply for that
type of bar.
Secure the high voltage cable from the static bar. Route the flexible conduit clear
of moving machine parts and other wiring. Bends in the conduit must not "kink".
Secure conduit using nylon wire ties (not supplied).
IQ Power BPS
12
5201249 Rev. D
