7. TROUBLESHOOTING

NOTE – Only qualified service personnel are to perform troubleshooting
tasks.
CAUTION – Electrical Shock Hazard
Do not troubleshoot high voltage components with power supply energized.
Disconnect input power or switch power off before troubleshooting.
PROBLEM
Clean Bar indicator
illuminated
Control Station not
working
Power indicator NOT
illuminated
COMM NOT illuminated
IQ Power BPS
CAUSE
Process material fouling static
bar ion emitters
Dirt build-up on ion emitters or
conductive contamination on
face of bar
Power not on at Control Station
Poor Electrical connections
Incorrectly wired modular cable
(check against cable illustrations
in Installation section)
Power not on at power supply
Poor electrical connections
Defective AC adapter
Power supply operating
stand-alone
Poor electrical connections
Power not on at other modules
25
SOLUTION
Remove process material from
static bar
Clean ion emitters and static
bar. See Maintenance section for
details
Turn on power switch near entry
module. Check line voltage
connections
Check connections of modular
cable at power supply control
station
Replace or repair modular cable
Turn on Power switch on end of
power supply case
Check input power connections,
both 24 VDC and line voltage
Replace AC adapter
Comm indicator only illuminates
if other modules are connected
Check connections of modular
cable at power supply and other
modules
Apply power/turn on other
modules
5201249 Rev. D
