Installation Instructions
V1.0
PIMT4
Thank you for choosing our product! We strive to provide the best
quality and services for our customers. Would you kindly share your
experience on Amazon if you are satisfied? Should you have any issues,
please don't hesitate to contact us.
Telephone：1-800-556-9829 Mon-Fri 10am - 6pm (PST) (USA) (CAN)
Email：supportus@pipishell.net (US/CA/DE/UK/FR/IT/ES/AU)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Pipishell PIMT4
Summary of Contents for Pipishell PIMT4
- Page 1 Installation Instructions V1.0 PIMT4 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us.
-
Page 3: Important Safety Information
•Check package contents against Supplied Parts and Hardware Lists to assure that all components were received undamaged. Do not use damaged or defective parts. lf you require replacement parts, contact customer service at supportus@pipishell.net •Not all parts and hardware included will be used. -
Page 4: Supplied Hardware
Supplied Hardware Hardware for Attaching TV Bracket to TV Spacers Washers [If necessary] [M-G] [M-H] [M-I] M4/M6 10mm TV Screws [Only one size fits your TV] [M-A] [M-B] M4 x 15mm M4 x 30mm [M-C] [M-D] M6 x 15mm M6 x 30mm [M-E] [M-F] M8 x 15mm... - Page 5 Step 1 Check TV Hole Pattern and Select TV Screws 100 mm ≈ 4 in. 200 mm ≈ 7 7/8 in. 400 mm ≈ 15 3/4 in. Only one screw size fits your TV. Step 2 Select Spacers (if needed) NO SPACER WITH SPACER Long Screw...
- Page 6 Too Short Too Long Step 3 Attach the TV Brackets to [02] and [03] Your TV No Spacer With Spacer Alternate Spacer Setups Step 4 Attach the Wall Plate [01] to Wall For wood stud installation, follow STEP 4A For concrete installation, follow STEP 4B Step 4A Wood Stud Option WARNING:...
- Page 7 4A-1 Use a stud finder(not included)to locate wood studs. Mark the edge and center locations. 4A-2 Position the wall plate[01] at your desired height and line up the holes with your stud center line. Level the wall plate and mark the holes. 55mm 4A-3 ø5mm...
- Page 8 Step 4B Solid Concrete or Concrete Block Option WARNING: ● Avoid potential personal injury or property damage! DO NOT over-tighten the lag bolts [A]. Tighten the lag bolts [A] only until they are pulled firmly against the wall plate [01]. Wall ●Ensure the wall plate[01] is securely fastened to the wall before Anchor...
- Page 9 4B-3 Use the hammer to knock anchors [B] into the wall. Be sure the anchors [B] are seated flush with the concrete surface. Install wall plate using lag bolts [A] and anchors [B]. Tighten the lag bolts [A] only until they are pulled firmly against the wall plate. DO NOT over-tighten the lag bolts [A].
- Page 10 Hang TV to the Wall Plate [01]. Step 6 HEAVY! You may need assistance with this step. Secure TV Step 7 Press Locking Pull down and hold both cords [R], press the bottom of the TV into the wall plate [01] until the latches lock the TV in place.
- Page 11 Remove the TV HEAVY! You may need assistance with this step. Unlocking Disconnect all cables, pull down and hold both cords [R] while gently pulling the bottom of the TV away from the wall. CAUTION: Avoid potential personal injury or property damage! To prevent breaking the locking latches: always pull and hold the cords [R] down while pulling the TV away from the wall.
