MEDIUM FULL-MOTION TV WALL MOUNT
V2.0
PIMFK1
Thank you for choosing our product! We strive to provide the
best quality and services for our customers. Would you kindly
share your experience on Amazon if you are satisfied? Should
you have any issues, please don't hesitate to contact us.
Telephone：800-556-9829
Mon-Fri 10am - 6pm (PST) (USA)
Email：supportus@pipishell.net
(US/CA/DE/UK/FR/IT/ES/JP/AU)

Advertisement

loading
Need help?

Need help?

Do you have a question about the PIMFK1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pipishell PIMFK1

Summary of Contents for Pipishell PIMFK1

  • Page 1 MEDIUM FULL-MOTION TV WALL MOUNT V2.0 PIMFK1 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us.

  • Page 2: Supplied Hardware

    WARNING! supportus@pipishell.net Tools Needed (Not Included) 7/32 in.(5.5mm) 2/5 in.(10mm) Wood Drill Wall Drill socket wrench socket wrench Supplied Hardware Spacers Philips Screws Philips Screws M8 x 65 Ø6mm Ø6mm Washers Spacers M6x15mm M6x30mm Lag Bolts Washers M4-5-6 L10mm L5mm...
  • Page 3 Step 1 Before TV Bracket Installation 2.95 in. 3.94 in. 7.87 in. 11.81 in. 15.75 in. Step 2 Install TV Bracket For Flat screen TV D1/ F...
  • Page 4 For Curved TV Step 3A These anchors are for concrete or brick walls ONLY. DO NOT use them in drywall or wood studs. Anchor 3A-1 3A-2 Ensure marking at the center of the stud.
  • Page 5 3A-3 3A-4 (5.5mm) 2 5/9 in.(65mm). socket wrench Step 3B Anchor These anchors are for concrete or brick walls ONLY. DO NOT use them in drywall or wood studs. 3B-1 3B-2 10mm Position the wall plate at your desired height, level the wall plate and mark the polit hole locations.
  • Page 6 3B-3 Use the hammer to knock anchors A3 into the wall. Install wall plate using lag bolts A1, washers A2 and anchors A3. Tighten the lag bolts until they are pulled firmly against the wall plate. Step 4 Mounting your TV to the Brackets and lock it.

  • Page 7: Step 6 Tilt Adjustment

    Step 5 Post Installation Level If needed, the TV can be leveled +/-3 degrees socket wrench Step 6 Tilt adjustment socket wrench -12° +5°...
