Installation Instructions
V1.0
PIMF3
Thank you for choosing our product! We strive to provide the best
quality and services for our customers. Would you kindly share your
experience on Amazon if you are satisfied? Should you have any issues,
please don't hesitate to contact us.
Telephone：800-556-9829 Mon-Fri 10am - 6pm (PST) (USA) (CAN)
Email：supportus@pipishell.net (US/CA/DE/UK/FR/IT/ES/JP/AU)
Advertisement
Table of Contents
Related Manuals for Pipishell PIMF3
Summary of Contents for Pipishell PIMF3
- Page 1 Installation Instructions V1.0 PIMF3 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us.
- Page 2 •Check package contents against Supplied Parts and Hardware Lists to assure that all components were received undamaged. Do not use damaged or defective parts.lf you require replacement parts, contact customer service at supportus@pipishell.net •Not all parts and hardware included will be used.
- Page 3 Supplied Hardware Hardware for Attaching Wall Plate to Wall Lag Bolts Washers Wall M8X65 Anchor CAUTION! These anchors are for concrete or brick walls ONLY. DO NOT use them in drywall or wood studs. Hardware for Attaching TV Bracket to TV Washers Spacers Spacers...
- Page 4 Step 1 Measure VESA and Check TV screws Measure the distance between the holes located at the back of your TV (these measures may form the shape of a square, or a rectan gle) and check that these taken measures are within the When attaching brackets to the flat VESA(*) range for this wall screen, be careful not to over...
- Page 5 ROUND BACK TV D2/F (UNIVERSAL MONITOR PLATE) C1/C2 C1/C2 First, make sure the diameter of the bolt(D1-F) fits your TV. Then, please see the diagram above. You will need to thread the bolt into the TV using the washer (B) and spacer (C1 or C2) if necessary with a screwdriver(Not included).
- Page 6 3A-1 3A-2 Use a stud finder (not included) to Ensure marking at locate wood stud. Mark the edge the center of the and center locatons. stud. Center line 3A-3 3A-4 Drill 4 pilot holes using A1 A2 a 7/32 in. (5.5mm) 7/32 in.(5.5mm) Mount the wall plate using 4 Wood Drill diameter...
- Page 7 WARNING: ● Mount the wall plate [01] directly onto the concrete surface ● Minimum solid concrete thickness: 203 mm (8 in.) ● Minimum concrete block size: 203 x 203 x 406 mm (8 x 8 x 16 in.) 3B-1 3B-2 Drill 4 pilot holes using a 25/64 in.(10mm) diameter...
- Page 8 STEP 4 Level Adjustment If needed, the TV can be leveled STEP 5 Hang the TV onto the wall plate Tilt adjustment Locking...
