- Page 1 INSTRUCTION MANUAL MANUEL D'INSTRUCTIONS Rev04(A) PIMFK3 Full-Motion TV Wall Mount Support Mural du Téléviseur à Mouvement Complet support@pipishell.net 1-800-556-9829 (US/CA) 44-808-196-3885 (UK) www.pipishellav.com WWW.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION • Please carefully read all instructions before attempting installation. If you DO NOT understand the instructions or have any questions or concerns, please call technical support or email customer service. • CAUTION: Avoid potential injuries and property damage! •... -
Page 3: Supplied Parts And Hardware
Tools Needed (NOT lncluded) Phillips 7/16″ (11mm) Tape Measure Pencil Electric Drill Socket Wrench Screwdriver For Wood Stud Installation For Solid Concrete and Brick Wall Installation 5/32″ (4mm) 3/8″ (10mm) Stud Finder Hammer Wood Drill Bit Concrete Drill Bit Supplied Parts and Hardware WARNING: This product contains small parts that may pose a choking hazard. - Page 4 TV Bolt (Only one size of the bolt fits your TV) NOTE: The bolts shown are actual size. M4 x 12mm M4 x 30mm [C1] x 4 [C2] x 4 M6 x 15mm M6 x 35mm [D1] x 4 [D2] x 4 M8 x 25mm M8 x 50mm [E1] x 4...
- Page 5 Step 1 Secure the TV Brackets to the TV Select TV Bolts Only one size of the bolt fits your TV Bolt length: Verify adequate thread engagement with bolts or bolts/spacers combination. We recommend thread engagement by at least 5 turns. -Too short will NOT hold the TV.
- Page 6 Option B: For Curved Back TVs Spacers must be tall enough so that the curved back of the TV does not interfere with the mounting plate. C2/D2/E2 B1/B2 F1/F2/F3 Alternate Spacer Setups Option C: For TVs with a “Bump” The TV brackets must be flush on the bump and leveled by spacers on the gap. C2/D2/E2 B1/B2 F1/F2/F3...
- Page 7 Option D: For TVs with Protruding Cables Use spacers to create extra space between the TV and TV brackets. C2/D2/E2 B1/B2 F1/F2/F3 Alternate Spacer Setups Option E: For TVs with Recessed Holes Spacers need to fill in the recessed holes on the back of the TV, while keeping the TV brackets as close to the TV as possible.
- Page 8 Step 2 Attach the Arm Assembly / Wall Plate [01] to the Wall For wood stud installation, follow STEP 2A. For solid concrete, or brick walls installation, follow STEP 2B. Step 2A Wood Stud Installation WARNING: ● Avoid potential personal injury or property damage! DO NOT use a drill for tightening the lag screws.
- Page 9 2A-3 Drill 3 pilot holes using a 5/32″ (4mm) diameter drill bit. Make sure the depth is NOT less than 2 3/4″ (70mm). 2 3/4″ (70mm) Electric Drill (NOT lncluded) 5/32″ (4mm) 2A-4 HEAVY! You may need assistance with this step. Mount the arm assembly / wall plate [01] using the lag screws [A1].
- Page 10 2B-1 HEAVY! You may need assistance with this step. Position the arm assembly / wall plate [01] at your desired height. Level the wall plate and mark the pilot hole locations. Pencil (NOT lncluded) 2B-2 Drill 3 pilot holes using a 3/8″...
- Page 11 2B-4 HEAVY! You may need assistance with this step. Mount the arm assembly / wall plate [01] using the lag screws [A1]. Tighten the lag screws [A1] only until they are pulled firmly against the wall plate. DO NOT over-tighten the lag screws [A1].
- Page 12 4-2 Hang the TV with brackets [02] on the arm assembly / wall plate [01]. 4-3 Retighten the pre-assembled bolts [S] to secure the TV to the arm assembly / wall plate [01]. HEAVY! You may need assistance with this step. Phillips Screwdriver (NOT lncluded)
-
Page 13: Tilt Adjustment
Step 5 Adjustments 5-1 Level Adjustment If needed, the TV can be levelled. Level 1. Slightly loosen four level nuts [L]. 2. Level your TV. CAUTION: Please DO 7/16″ (11mm) NOT over-tighten or 3. Retighten four level nuts [L] to Socket Wrench over-loosen the nuts. -
Page 14: Frequently Asked Questions
Frequently Asked Questions Question 1: How can I raise/lower the TV if the TV Wall Mount is already fixed on the wall? 1. Remove the TV from the TV Wall Mount. 2. Remove the TV brackets from the TV and reattach according to instructions A or B in the picture below (A for lifting up the TV or B for lowering the TV).
