INSTALLATION INSTRUCTIONS
SPECIFICATIONS - MODEL NO. IS1200
4
6
1
6
5
130
4
95
530
CO-AXIAL FLUE CONFIGURATION
3
2
SINGLE FLUE CONFIGURATION
3
2
530
6
1 Co-Axial Manifold Flue Starter 65mm
2 Electric Cord
3 1/2" BSP Gas Connection (Inside)
4 Air Inlet
5 Air Inlet Spacer
6 Flue Exit Point
7 Single Flue Adaptor
8 Single Flexi Flue (suit 40mm pipe)
8
7
