THE AETHER
INSTALLATION AND USER MANUAL
AURORA WOODFIRES INSTALLATION AND USER MANUAL
+612 66868408 PO 347 BOX BYRON BAY
NSW 2481

Advertisement

loading
Need help?

Need help?

Do you have a question about the THE AETHER and is the answer not in the manual?

Questions and answers

Related Manuals for Aurora THE AETHER

Summary of Contents for Aurora THE AETHER

  • Page 1 THE AETHER INSTALLATION AND USER MANUAL AURORA WOODFIRES INSTALLATION AND USER MANUAL +612 66868408 PO 347 BOX BYRON BAY NSW 2481...

  • Page 2: Table Of Contents

    CONTENTS PLANNING DIMENSIONS & SPECIFICATIONS INSTALLATION USING THE AETHER TESTING KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266 868408 PO 347 BOX BYRON BAY NSW 2481...

  • Page 3: Planning

    1. PLANNING We would like to thank you for your purchase of The Aether.The care and craftsmanship we put into each fire will give you trouble free heating for many years to come. For your safety, ensure you have read the operation guidelines prior to use. The Aether should be installed by a qualified professional.
  • Page 4 IMPORTANT: Frames must also be considered. Timber window frames must be treated as combustible surfaces. Aluminium frames can be treated as non- combustible surfaces AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266 868408 PO 347 BOX BYRON BAY NSW 2481...

  • Page 5: Dimensions & Specifications

    • Finish: high temperature coating system. Resistant to 650 degrees MATTE BLACK A range of other colours are available on request. For more information visit our website: www.aurorawoodfires.com AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266 868408 PO 347 BOX BYRON BAY NSW 2481...

  • Page 6: Installation

    • 12mm ventilation gap between the plasterboard and the ceiling flange • 25mm minimum clearance from the triple skin flue to any combustible material within the roof space AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266 868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 7 3. INSTALLATION (CONTINUED) PITCHED ROOF INSTALLATION (Custom Made Bracket) AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266 868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 8 The minimum height of the flue system further than 5 meters from the highest point of the roof shall be 1 meter above roof penetration. AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266 868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 9 The minimum height of the flue system further than 5 meters from 1 meter the highest point of the roof shall be 1 meter above roof penetration. AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266 868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 10 • The first 6 inch stainless flue has an adaptor connected to it. • PLEASE REFER TO 3.4 FOR A STEP BY STEP GUIDE TO INSTALLING FIRST LENGTH OF 6 INCH FLUE. Dropbox AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 11 Push the the 6 inch stainless flue into the top of the lower Screws active flue as far as it will go until it bottoms out. AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 12 You will also find that the FlueCube makes your fire much easier to light and will slow the rate at which the fire burns fuel due to improved efficiency. AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY...
  • Page 13 2. Push the FlueCube down until it rests on the top of the spacer. 3. Attach the outer clamp to secure the Top spacer bracket 6 inch inner flue 10 inch outer flue AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 14 Ball Bearing Shaft Pivot Lower plate Stainless Thrust Bearing Ball Bearing Cap 16mm Nut NOTE: The bearings are shipped in the correct order on the shaft. AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 15 3. INSTALLATION (CONTINUED) Locking Plates To secure the firebox in a fixed position please install the locking plates as shown. AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 16 • If the combustible floor is installed on concrete, you can replace the combustible material with a non-combustible material laid directly onto the concrete. • See over page for height specifications. AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY NSW 2481...
  • Page 17 floor surrounding it Note: Non combustible finishes can be applied to the floor protector, e.g. tiles, stone, metal. Floor protector 30cm 30cm 650mm Floor AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY NSW 2481...

  • Page 18: Using The Aether

    • THIS APPLIANCE SHOULD BE MAINTAINED AND OPERATED AT ALL TIMES IN ACCORDANCE WITH THESE INSTRUCTIONS. • THE USE OF SOME TYPES OF PRESERVATIVE-TREATED WOOD AS A FUEL CAN BE HAZARDOUS. • DO NOT TOUCH THE FIREBOX OR FLUE WHEN HOT. AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY...
  • Page 19 fireplace. Once this initial firing process is successfully completed, the coating will bond to the metal with a colourfast finish that will last for years AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY...
  • Page 20 Ventilate and vacate the room to avoid discomfort. Repeat this process twice. Once these burns are complete there will be no odour or smoke the next time the stove is fired. AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY...
  • Page 21 Please visit the Stove Bright website for a range of easy to follow video’s which will take you through the process of touching up your paint. http://forrestpaint.com/stove-bright/how-tos-with-stove-bright AURORA WOODFIRES INSTALLATION AND USER MANUAL +61 266868408 PO 347 BOX BYRON BAY...

  • Page 22: Testing

    5. TESTING TESTING LABORATORY: Vipac Engineers & Scientists MANUFACTURER: Aurora Wood Fires Pty Ltd MODEL: The Aether TEST REPORT NUMBER: 30A-14-0097-TRP-359162-0 TEST DATES: 25 January 2015 to 30 January 2014 CONCLUSION: This appliance meets the requirements of AS/NZS 4013:2014 section 1.2.3 (f)
