- Page 1 INSTALLATION AND USER MANUAL THE ELEMENTAL SUSPENDED FIRE Bioethanol www.aurorasuspendedfires.com +61 (0) 2 6686 8408 | 4/1 Simmons Street | Ballina NSW 2478, Australia...
-
Page 3: Table Of Contents
We would like to thank you for your purchase of an Aurora Suspended Fire. The care and craftsmanship we put into each fire will give you trouble free heating for many years to come. CONTENTS 1. PLANNING INTRODUCTION CLEARANCE TO COMBUSTIBLES 2. -
Page 5: Planning
PLANNING... -
Page 6: Introduction
6. Fit the washers and nuts to secure the firebox Mixing of appliance or flue-system components from different sources or modifying the dimensional specification of components may result in hazardous conditions. Where such action is considered, Aurora fires should be consulted in the first instance. -
Page 7: Clearance To Combustibles
AURORA SUSPENDED FIRES CLEARANCE TO COMBUSTIBLES A combustible surface is anything that can burn (i.e. plaster, wall paper, wood, fabrics etc.) These surfaces are not limited to those that are visible, but also include materials that are behind non-combustible material. Timber frames behind gyprock are considered combustible. -
Page 9: Dimensions & Specifications
DIMENSIONS & SPECIFICATIONS... - Page 10 DIMENSIONS & SPECIFICATIONS INSTALLATION AND USER MANUAL THE ELEMENTAL FEATURES WEIGHT & DIMENSIONS · Material: 3mm Steel Firebox length 950mm · Finish: high temperature Firebox width 360mm coating system Firebox height 440mm · Heat Output: 3.4kW Firebox weight 80kgs · Colour: matte black (A range of other colours are Flue weight 15kg/m...
- Page 11 AURORA SUSPENDED FIRES CEILING BRACKET FLUE FIREBOX...
-
Page 13: Installation
INSTALLATION... -
Page 14: Suspension Bracket
SUSPENSION BRACKET FLAT CEILING INSTALLATION: The bracket must be structurally secured within the roof, as shown on the diagram. The large square body of the ceiling bracket must protude down through the fi nished ceiling level by a minimum of 25mm. You must leave a 25mm clearance gap between the bracket and the ceiling. - Page 15 AURORA SUSPENDED FIRES » PITCHED CEILING INSTALLATION Custom Made For pitched ceilings we have 5 bracket sizes which your installer will adjust to achieve the exact angle for your installation. · Up to a 5 degree pitch = Flat bracket ·...
-
Page 16: Lower Flue
INSTALLATION INSTALLATION AND USER MANUAL LOWER FLUE LOWER FLUE LENGTHS We supply the lower flue in the standard sizes listed below. The extra length will be pushed up into the ceiling bracket, enabling you to set the correct distance of the firebox to the floor. - Page 17 AURORA SUSPENDED FIRES INSTALLING THE INTERNAL LOWER FLUE The lower acti ve fl ue is delivered with additi onal length to allow for small changes to set the correct fi rebox height. 1. First positi on the lower fl ue inside the suspension bracket 900mm from the fl oor.
-
Page 18: Firebox
INSTALLATION INSTALLATION AND USER MANUAL FIREBOX ENGAGING THE FIREBOX 1. Ensure the lower flue is the correct height from the floor 2. Use a jacking trolley to lift the firebox evenly onto the 4 fixing bolts 3. Fit the blanking plate to cover the opening in the flue 4. -
Page 19: Bioethanol Fireplace
AURORA SUSPENDED FIRES BIOETHANOL FIREPLACE The Elemental fireplace is fitted with an EcoSmart XL500 burner which uses bioethanol fuel. As bioethanol gives off nothing but water vapour there is no need for an external flue. The lower active flue will be... -
Page 20: For Installers
INSTALLATION INSTALLATION AND USER MANUAL FOR INSTALLERS CLEANING UP If the fire paint has accumulated dust, fingerprints or other residue during installation Wipe the firebox and lower flue down with a little water and a scratch free glass polishing cloth. Use a light spray of WINDEX if required. DO NOT RUB THE PAINT. -
Page 21: Installation Checklist
1mm to 2mm. IMPORTANT This must be ticked and signed by the person who installs your fire and returned to aurora suspended fires following installation for any warranty claims to be honoured. NAME SIGNATURE... - Page 22 Aurora +61 (0) 2 6686 8408 4/1 Simmons Street Ballina NSW 2478, Australia www.aurorasuspendedfi res.com...
