INSTALLATION INSTRUCTIONS
Bolted surround / Landscape surround - Fitment continued
Fit 8Gx12mm Button
self tapping screw.
Once the surround is screwed in position, then fit the
bottom door flap, fit the right hand side with the door
stop tab first, then line up left plunger and place in
position with receiver.
21
Once the surround is hung on
the heater, then line up holes in
both side panels and fit the
8Gx12mm screws in place to
hold the surround in place.
Fit 8Gx12mm Button
self tapping screw.
