- Page 1 Effective January 2016 INSTALLATION & OPERATING Australian Patent INSTRUCTIONS PN 200110001S Serial Number: B.D. Number: Model: IS720G PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Aurora CLIMATE SYSTEMS A.B.N. 43 108 083 987...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY LABEL OPERATING INSTRUCTIONS To The New Owner Automatic Humidifier Operation Safety Labels Operating Instructions Checklist 24-25 Remote Control Start Up & Adjustment 26-27 INSTALLATION INSTRUCTIONS Fan Operation & Shut Down Instructions Lighting Instructions Manual Specifications Remote Control Operation 30-36 General Safety Information High Temperature Cut Out... -
Page 3: To The New Owner
FITTER/ INSTALLER. TO DO SO WILL VOID YOUR WARRANTY. It is policy of Aurora Climate Systems that should a fault develop in the Archer Gas Space Heater during its warranty period, Aurora will repair the appliance. However we wish to advise that should the Archer Gas Space Heater develop a fault in its operation because the product was not installed in accordance with the manufacturer’s... - Page 4 Note: If this appliance is installed by a licensed gas fitter who is not familiar with the installation of the heater, we recommend that prior to installing the appliance the installer contact Aurora to obtain further advice on the installation of the product. FOR YOUR SAFETY...
-
Page 5: Safety Labels
2 Mtr Flex standard 3 Pin Plug Note: In case of power cord damage, replace only with Archer special cord set. Obtainable from your Archer Dealer or direct from Aurora Climate Systems. DO NOT MODIFY THIS APPLIANCE DO NOT OPERATE THIS APPLIANCE BEFORE READING THE... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS SPECIFICATIONS - MODEL NO. 720 G 1 Co-Axial Manifold Flue Starter 65mm 2 Electric Cord 3 1/2” BSP Gas Connection (Inside) 4 3 Sided Surround (885 x 742) 5 Air Inlet Cover Plate 6 PVC Exhaust Pipe 40mm 7 Flue Exit Point (centre line) 8 Single Flue Adaptor 9 Single Flexi Flue (suit 40mm pipe) -
Page 7: General Safety Information
INSTALLATION INSTRUCTIONS GENERAL SAFETY INFORMATION 1. This installation must conform with local codes or, in the absence of local codes, with AS 5601. 2. Provide adequate clearances around the product for servicing and ensure there are no obstructions to the combustion air intake situated at the back of the heater. -
Page 8: Clearances To Combustibles
15mm Note: The Archer Gas Space Heater has been tested and approved for zero clearance to combustible materials. Aurora Climate Systems recommends that clearances as listed above should be maintained to allow for removal of the product for servicing. These clearances must be maintained to allow combustion air to enter the... -
Page 9: Flueing Requirements
INSTALLATION INSTRUCTIONS FLUEING REQUIREMENTS Co-Axial Flue Installations Note: This appliance has been approved for co-axial flue application. If the flue (as supplied by the manufacturer) is installed to an external wall or external fireplace. (Refer installation diagram for Co-Axial Flue Installations Pages 10-11-12) Single Flexi Installations Note: This appliance has been approved for single flue pipe installation. -
Page 10: Flueing Options Installation
FLUEING OPTIONS INSTALLATION SINGLE FLUE KIT FOR ARCHER GAS SPACE HEATER For applications on Flexible Single Flue refer to pages 9-12-13-14-15 Description Single Flue Adaptor Supplied with heater 40mm ø PVC Pipe 400mm long Supplied with heater 90° PVC Bend Supplied with heater 40mm ø... - Page 11 FLUEING OPTIONS INSTALLATION CO-AXIAL FLUE KIT FOR ARCHER GAS LOG SPACE HEATER For applications refer pages 10-11-12 of this Installation Manual. Description Co-Axial Manifold Starter (factory fitted) Ø40mm PVC Pipe 400mm Approx. Ø65mm PVC Pipe 400mm Co-Axial Flue cowl Notes: 1/ When connecting 40mm Ø...
- Page 12 FLUEING OPTIONS INSTALLATION INSERT MODEL IS720 G -With Co-Axial Flue - Exterior Masonry Fireplace Co axial Flue Pipe up to 1 metre long 1/2” BSP Gas Connection Note: Do not use PVC cement to seal flue pipe connections to allow for removal of flue pipe.
- Page 13 FLUEING OPTIONS INSTALLATION CREATED FIREPLACE MODEL IS720G Zero clearance, power flue, single 40mm flue and shallow unit depth allow you to create your own fireplace anywhere in your home with your choice of mantel. Note: Heater must be able to be removed easily for servicing. (Not locked in) 500mm 5100mm Maximum...
- Page 14 FLUEING OPTIONS INSTALLATION Internal to External Wall Installation using 40mm ø PVC Flue. Side Wall Installation (Horizontal Single Flue) External Wall Internal Wall 75mm cowl to suit 40mm PVC flue 90º Elbow pipe. Concrete Slab 40mm PVC Pipe CAUTION: DO NOT ALLOW WATER TRAPS TO FORM IN FLUE OR HEATER WILL CEASE TO OPERATE.
- Page 15 FLUEING OPTIONS INSTALLATION Flexible Flue Kit to suit Fireplace Insert Installations Model IS720G STANDARD FLUE KIT SUPPLIED BY AURORA FOR INSERT INSTALLATION (SFA002) Note: Standard 75mm Cowl to fit 40mm ø pipe is also supplied with flue kit. 40mm N.B. Plain Coupling (Supplied with Flue Kit) (38mm I.D.) 50mm Nylaflow Flexible Hose Nylaflow G.P.
- Page 16 FLUEING OPTIONS INSTALLATION Fireplace Insert Installation Model IS720G -Using Aurora Flexible Flue Kit SFA002 with Single 40mm PVC Flue Pipe using 75mm cowl Fasten 40mm Flue Pipe with Gas Cowl Supplied bracket to stop flue pipe in flue kit being forced downwards...
-
Page 17: Gas Connection
INSTALLATION INSTRUCTIONS GAS CONNECTION (Line Supply) The gas connection is 1/2” BSP supplied in heater. GAS SUPPLY LINE TO HEATER Remove the 2 screws on top L/H front side panel and lift out side panel. Remove rubber grommet from back panel of heater and insert 1/2” copper gas supply line through back panel of heater. -
Page 18: Outlet Pressure Adjustment
INSTALLATION INSTRUCTIONS 843/845 OUTLET PRESSURE ADJUSTMENT All adjustments must be made on the basis of the specific characteristics of the appliance. Check inlet and outlet pressure using the pressure test points provided. After testing, carefully seal test points with the provided screws. Recommended torque: 1.0 Nm. -
Page 19: Decorative Glass Installation
DECORATIVE GLASS ACCESSORY PLACEMENT Note: the IS720 Archer Heater will accept two square feet of decorative media. Aurora climate systems offers a selection of decorative media for the IS720 Archer Heater. It is approved for use with glass media measuring as small as 1/4 inch and up to 1-1/4 inch in diameter. -
Page 20: Wiring Diagram
INSTALLATION INSTRUCTIONS WIRING DIAGRAM WARNING Potential risk of fire, electric shock, and This appliance is equipped with a three—pin personal injury. Take precautions to plug for your protection against shock reduce such risks. hazard. It should be plugged directly into a properly grounded three—pin receptacle. -
Page 21: Start Up Checklist
START UP CHECKLIST WARNING BEFORE OPERATING THIS APPLIANCE, CAREFULLY READ THE FOLLOWING Verify the gas line service does not exceed 2.5 kpa, 250mm and is not below 1.25kpa, 125mm for natural gas, nor exceeds 3.3kpa, 330mm or is below 2.75kpa, 275mm for LP gas. -
Page 22: Safety Screen Installation
INSTALLATION INSTRUCTIONS MAIN DOOR SAFETY SCREEN INSTALLATION CHILDREN AND ADULTS SHOULD BE ALERTED TO THE HAZARDS OF HIGH SURFACE TEMPERATURE FROM THE MAIN DOOR GLASS AND SHOULD STAY AWAY TO AVOID BURNS OR CLOTHING IGNITION. YOUNG CHILDREN SHOULD BE CAREFULLY SUPERVISED WHEN THEY ARE IN THE SAME ROOM AS THE APPLIANCE. -
Page 23: Insert Surround Assembly/Fitting
INSTALLATION INSTRUCTIONS ASSEMBLY AND FITTING OF BOLTED SURROUND FOR IS 720 Hook Tabs Fit 2x M5x8+M5 Nut Note: when fitting side panels, keep them to the outside as much as Plunger Receiver's Fit 2x M5x8+M5 possible. Left side panel Plunges Bottom Door Flap Fit 2x M5x8+M5 Nut Right side panel... -
Page 24: Automatic Humidifier Operation
AUTOMATIC HUMIDIFIER OPERATION Most gas heaters dry out the air in the room. (Remember the bowls of water in front of the old gas heaters?) The Archer has ingeniously solved this problem with an Automatic Humidifier. Gas contains moisture which is normally expelled out the flue or chimney after combustion. -
Page 25: Operating Instructions Checklist
Archer Heater. Installers who are not familiar with the installation of this appliance should contact Aurora Climate Systems prior to installing the appliance to avoid creating hazardous operating conditions. No deviations on installation are allowed, unless they are specifically approved in writing by the manufacturer of the appliance. - Page 26 Check and verify that flue pipe connection to the appliance when using single 40mm flue pipe and co-axial flue pipe installation is correctly installed and secured in line with instruction in the Installation Manual Pages 9-16. Prior to operating the appliance check for dust or glass particles lying on top of the burners.
-
Page 27: Remote Control Start Up & Adjustment
START UP AND ADJUSTMENTS WITH REMOTE With main electrical power to the fireplace turned off, install three AAA 1.5V Batteries into the remote. Set up remote per instructions on pages 31-36. After the remote is set up, ensure that the remote is turned on and active. - Page 28 START UP AND ADJUSTMENTS WITH REMOTE Sequence of operations 1. Start the fireplace with the remote, or press the display panels “Mode Select” button (figure 49) to start the fireplace manually. The display panel will energize, and the desired flame level will be displayed. 2.
-
Page 29: Fan Operation & Shut Down Instructions
FAN OPERATION The 3-speed main convection fan will cut in automatically approximately 3 to 5 minutes after the heater warmed Note: 3-speed main convection automatically controlled and will operate on three preset speeds. Depending on your heat setting and the surround- ing ambient temperature. -
Page 30: Lighting Instructions Manual
LIGHTING: INSTRUCTION MANUAL OPERATION Starting the Heater—Display Panel If the remote control is inoperable due to being damaged or having dead batteries, the Heater display panel may be used to operate the fireplace instead. Note: When operating the fireplace manually from the display panel, only basic operations are available: On, Off and flame level adjustment 1. -
Page 31: Remote Control Operation
REMOTE INSTRUCTIONS Position of room temperature sensor LCD display ON-OFF/PILOT Key MANUAL-AUTOMATIC KEY UP-DOWN arrow key FUNCTION (SLEEP-PROGRAM) (*) Key or keyboard lock-release (**) Base and battery compartment Ref. Icon Description ON-OFF/PILOT MANUAL-AUTOMATIC mode Increase Decrease 5’ SLEEP-PROGRAM mode (*) Keyboard lock-release (**) When the remote shows “PILOT”... - Page 32 REMOTE INSTRUCTIONS LCD DISPLAY Functioning mode symbol (MANUAL-THERMOSTATIC –PILOT) Digits identifying the weekly TIMER program currently selected. Clock setting symbol. When this symbol appears, you can adjust the clock setting displayed by the digits. Flame power bars: 1 bar = level 1, 2 bar = level 3, 3 bar = level 3, 4 bar = level 4. 5 bar ...
- Page 33 REMOTE INSTRUCTIONS TIMER symbol. If this symbol does not appear, the TIMER is not active. If only the outline of the symbol appears, the TIMER is active. A solid black symbol indicated that your are in the TIMER setting menu. Symbols indicating the current day.
- Page 34 REMOTE INSTRUCTIONS Battery Insertion Insert 3 AAA batteries into the battery compartment of the remote, paying attention on direction of insertion, do not mix battery types and use only new batteries Setting the clock As soon as the batteries are newly inserted the time can be set. Using the keys the hour can be increased or decreased as required using the 24 hour time format, Using the O key confirms the hour setting.
- Page 35 REMOTE INSTRUCTIONS Automatic/Manual mode selection With fireplace operating, by pressing key the operational mode is switched from manual to automatic and vice versa. When switched from MAN to AUTO, the flame level is set on level 1. When automatic mode is active, the display shows the SET temperature value and the “AUTO”...
- Page 36 REMOTE INSTRUCTIONS Crono Program Function The CRONO function can be set after pressing O key until symbol appears. Using the buttons this will change the program from P01 to P10 according to the program below. When the Program is active the symbol will appear.
- Page 37 REMOTE INSTRUCTIONS Appliance LCD Fault Code In the unlikely event of the fireplace operating there are a number of fault codes that will be displayed on the LCD display on the appliance. These codes do not display on the remote handset.
-
Page 38: High Temperature Cut Out
OVER TEMPERATURE CUT OUT The Archer Gas Space Heater is protected against overheating with a high temperature 80°C cut out switch to protect the heat exchanger, plastic sump and flue fan. The high temperature cut out switch will automatically switch off the gas supply to the heater, if the temperature in the room where the heater is located reaches approximately 28°C. -
Page 39: Unit Operating Faults
UNIT OPERATING FAULTS SERVICE AND INSTALLATION OF THE APPLIANCE SHOULD BE CARRIED OUT BY AUTHORISED PERSONNEL ONLY. THE MAJOR CAUSE OF OPERATING PROBLEMS WITH GAS LOG SPACE HEATERS IS IMPROPER GAS PRESSURE, IMPROPER INSTALLATION, INCORRECT FLUE INSTALLATION, OPERATION (REMOTE CONTROL), DIPS/SPIKES IN THE INCOMING POWER OR REVERSE POLARITY’S. -
Page 40: Resetting The Heater
RESETTING THE HEATER If for any reason the Heater needs to be reset. Open the front panel from the Heater to access the control compartment. If an error is present requiring that the Heater be reset. The code for the error will be displayed on the display panel along with the reset notification Refer to page 40 for a list of error codes and how to resolve each. -
Page 41: Troubleshooting
TROUBLESHOOTING LCD FAULT CODES ON THE DISPLAY PANEL FAULT LCD Digits Description ACTION DESCRIPTION Anomaly as parasitic Desired Yellow LED permanently OFF Turn off main power to the fireplace for 30 minutes. flame, APT failure flame level Green and LED blink slowly and simultaneously ... -
Page 42: Maintenance
Follow the directions for removing the glass door. If the liners need to be replaced, contact a qualified service person. Only liners provided by Aurora Climate Systems can be used, any substitute will void the warranty. MAIN CONVECTION FAN The main convection fan in the heater should be checked, serviced and cleaned annually by a qualified service person to ensure that your appliance is operating efficiently. -
Page 43: Gold/Chrome Plated Doors
GOLD PLATED/CHROME PLATED/STAINLESS STEEL DOORS The gold and chrome plated finish on the door requires little maintenance and needs only to be cleaned with a soft cloth and a small amount of Mr. Sheen. Polish gently. Stainless Steel doors can be cleaned with a metal cleaner that can be used on Stainless Steel. Please note: Stains or imperfections on plated finishes are not covered under warranty. -
Page 44: Frequently Asked Questions
If the paintwork on the heater is damaged or scratched, can I purchase touch up paint? Yes. Aerosol cans are available with the colour from your place of purchase of the heater or direct from Aurora Climate Systems. - Page 45 FREQUENTLY ASKED QUESTIONS Fan Noise The Heater has 3 Fans incorporated into the operating system 1. Flue Fan Motor Noise Levels The Flue Fan Motor is located in the rear of the heater as the flue fan motor operates on 340 RPM there will be a high pitched noise on start up of the heater with constant noise level resent from the flue fan when the heater is in operation.
-
Page 46: Complete Unit Warranty
It is the policy of Aurora that should a fault develop in the Archer Gas Log Space Heater during its warranty period, Aurora will at its own option either fix or repair the appliance in accordance with its present warranty policy. Also the policy of Aurora Climate Systems is if this Archer Gas Log Space Heater is found to be defective in materials or workmanship, Auro- ra Climate Systems will repair or replace such defects in the Archer Gas Log Space Heater at Aurora’s option in... - Page 47 Aurora Climate Systems for inspection or functionality check. Freight or postage both ways is to be paid by the owner. If Aurora finds a fault with the device they will repair or replace it under the normal warranty terms (1 Year).
- Page 48 Freight. Note: Aurora accepts no responsibility and shall not be liable for any damage caused in transportation or freight to the appliance that results in losses of any kind. Hot Surface Igniters.
- Page 49 NOTES 49 48...
- Page 50 NOTES...
- Page 51 ATTENTION APPLIANCE INSTALLER PLEASE RETURN THESE OPERATING & INSTALLATION INSTRUCTIONS TO THE CONSUMER (FOR FUTURE REFERENCE) DATE OF PURCHASE...
