INSTALLATION INSTRUCTIONS/ REQUIREMENTS
GENERAL SAFETY INSTALLATION REQUIREMENTS INFORMATION
1. This installation must conform with local codes or, in the absence of local codes, with AS/NZSG 5601.1
2. Provide adequate clearances around the product for servicing and ensure there are no obstructions to the combustion
air intake situated at the back of the heater. (Refer Page 8)
3. The appliance must be installed level on a flat, solid continuous surface (i.e. wood, metal, concrete). Please
Note: Rough or uneven surfaces can cause operating failure, vibration or humming in the heater.
4. The Archer Gas Log Space Heater can be installed in a wide variety of ways and will fit nearly any room layout. It
may be installed in a recessed position, framed out into the room, or across a corner. For installation options refer
pages 24 through to 32.
5. This appliance (Insert Model) needs to be installed in such a w ay that the heater
can be removed at all times to service the heat exchanger, flue fan, over temp switch and thermistor which are
located in the rear section of the heater.
Note: Under no circumstances should the appliance be installed under conditions, which would not allow
for easy removal of the appliance to carry out routine inspection and service to the appliance, to do so will
void the warranty.
Note: On co axial single flue pipe (imitation zero clearance fireplace) a minimum of 25mm clearance must be
provided at the rear side and top of heater (Refer page 10)
Note: Where a mantel surround is being used on insert installations and imitation zero clear ance fireplace
installations, the combustion air intake slot located in the top mantel surround must have no obstructions t o allow
combustion air to enter through the slot to the combustion air inlet located at the back of the heater.
Note: Electrical connection/ insert models
In cases where the heater is directly wired into the 240 volt main power with the connection being behind the
heater not accessible to isolate the heater from main power an external isolation switch is required to allow
the heater to be disconnected from main power to allow for servicing of the heater.
!
!
!
!
!
IN CASES WHERE THE INSTALLATION OF THE HEATER IS NOT IN ACCORDANCE WITH THE
MANUFACTURERS INSTRUCTIONS AND THE APPLIANCE CAN NOT BE REMOVED FOR SER-
VICING IN SUCH CASES WHERE SERVICE PERSONAL HAVE TO SPEND TIME TO REMOVE
THE HEATER OR CORRECT THE INSTALLATION A SERVICE CHARGE WILL BEA PPLICABLE
TO THE CUSTOMER OF LABOUR AT $80 PER HOUR PLUS GST PLUS TRAVELING EXPENSES.
THIS APPLIANCE SHOULD ONLY BE INSTALLED BY A QUALIFIED LICENSE D GAS FITTER.
DUE TO HIGH TEMPERATURES, THE APPLIANCE SHOULD BE LOCATED OUT OF TRAFFIC AND
AWAY FROM FURNITURE AND DRAPERIES .
THIS APPLIANCE CAN ONLY BE FLUED IN ACCORDANCE WITH THE MANUFACTURER'S IN-
STRUCTIONS AS TESTED TO AGA CODE 601.
FAILURE TO INSTALL THIS APPLIANCE CORRECTLY IN LINE WITH THE MANUFACTURER
INSTALLATION REQUIREMENTS WILL CAUSE MALFUNCTION OF THE HEATER AND MAY
CAUSE A SERIOUS HOUSE FIRE.
