Control Unit Specifications

Control Unit Specifications
Specification*
Hardwired Intercom Audio
Channels
Active Radio Packs
No. of Paired Radio Packs
Supported (per CU)
USB Ports
Front Panel LCD Display
Stage Announce and GPO
Closures
CrewNet Ports (supports two
connections)
Sync In Ports (supports one
connection)
2-Wire Intercom Connection
2-Wire Compatibility
4-Wire Intercom Connection
Stage Announce Output
Aux IN
Aux OUT
LAN Port
Power Input/Connector
Dimensions
Weight
Operating Environment
CCU-22
4
18 (requires use of 3 RTs.)
255
(1) USB Type A; (1) Micro USB
512 × 128 resolution
5 Relays via DA-15
(2) RJ-45 for copper; (1) duplex LC for Single Mode Fiber
(1) RJ-45 for copper; (1) duplex LC for Single Mode Fiber
2 ports via XLR 3F
with XLR 3M loop (2 ports)
Clear-Com, RTS, and AudioCom (Balanced)
2 ports via RJ-45
XLR 3M, balanced, transformer isolated
6.35 mm (1/4 in.) 3 conductor jack, 17.5 dBu max in (nominal line level +5 dBu),
balanced, transformer isolated
6.35 mm (1/4 in.) 3 conductor jack, 17.2 dBu into 600 ohms (nominal line level +5
dBu), balanced transformer isolated
(1) RJ-45 10/100 BASE-T 802.3 compliant
100–240V ~ 50–60 Hz, 0.8A
1 RU, 48.26 cm × 4.39 cm × 29.67 cm
(19.00 in. × 1.73 in. × 11.68 in.) metal enclosure
2.7 kg (5.9 lbs)
-20° to 50° C (-4° to 122° F); 10% to 90% Humidity.
CCU-44
8
4 ports via XLR 3F
with XLR 3M loop (4 ports)
4 ports via RJ-45
2.9 kg (6.5 lbs)
Product Specifications - 80
