Pliant Crewcom CCU-22 Operating Manual page 41

2. Navigate down the list of menu options until Upload System Configuration is highlighted.
3. Press the Master CU's enter button and scroll until you find the configuration file you wish to use, then press
enter to select it.
Note: Only CCFs that have been properly named with 8 characters or less will be
available for selection from this list. See
more information.
4. Confirm your selection when prompted by selecting Yes .
5. The Master CU screen will display a progress message while the new configuration file loads.
Figure 11 CU LCD Upload Configuration File Prompt
Figure 12 CU LCD List of Available Configuration Files
"Save Configuration File (CCF)" on page 51
Figure 13 CU LCD: Sample CCF Upload In Progress Screen
for
Setup and Installation - 33
