Wired Settings

The CrewCom wired settings can be configured depending on user preferences. The following settings and processes
can be found in the CU's menu under Wired Settings. (You can access this area of the menu by pressing the Wired
button on the front of the Control Unit.)
These settings can also be managed using CrewWare. (See the
information.)

Intercom Settings Menu

This CU menu option displays all the 2-Wire and 4-Wire settings on the CU LCD. Due to LCD size constraints, only four
ports are viewable at a given time. Use the Navigational Controls on the front of the CU to scroll through devices and
ports and move from setting to setting. Use the Enter button to select a setting for editing.
Tip: If you wish to edit the intercom settings via CrewWare, use the CU Management tab.
A. Device: Displays the selected device's name.
B. Port: Displays the individual device ports for which intercom settings can be adjusted.
Figure 25 Intercom Settings LCD Display
CrewWare Manual for more
Operation - 52
