Aux In Connection
To connect Aux IN, connect an audio source to Aux IN via the 1/4 in. (6.35 mm) TRS jack. Then, configure the
connection using either the CU or CrewWare.
Configure Aux In via CU
Audio supplied to Aux IN can be assigned to any combination of up to 10 possible Conferences under the Control
Unit's Wired Settings menu.
The default setting for Aux IN Level is "0."To adjust the Aux IN level, press Menu to open the main menu, scroll
through the menu options to the Wired Settings, and select Aux In.
1. Use the navigation controls to scroll to the Master Level bar. Press Enter to select it.
Note: Individual Aux In assignment level adjustments are not currently supported.
2. Use the navigation controls to adjust the current value displayed on the LCD.
3. Press Enter to save; or Menu/Home to escape without saving changes.
Audio levels are expressed as a numerical value from -10 to +10. Aux In assignments can be muted or unmuted from
this menu as well.
Configure Aux In via CrewWare
See the CrewWare Manual
Figure 31 Aux IN Level
for more information about this process.
