Aux Out Connection
To connect and configure Aux OUT, connect an external device to Aux OUT via the 1/4 in. (6.35 mm) TRS jack. Then,
configure the connection using either the CU or CrewWare.
Configure Aux Out via CU
Audio supplied from Aux OUT can be assigned from any single Conference under the Wired Settings menu.
The default setting for Aux OUT Level is "0." To adjust the Aux OUT level, press Menu to open the main menu, scroll
through the menu options to the Wired Settings, and select Aux Out.
1. Use the navigation controls to scroll to the Master Level bar. Press Enter to select it.
Note: Individual Aux Out assignment level adjustments are not currently supported.
2. Use the navigation controls to adjust the current value displayed on the LCD.
3. Press Enter to save; or Menu/Home to escape without saving changes.
Audio levels are expressed as a numerical value from -10 to +10. The Aux Out assignment can be muted or unmuted
from this menu as well.
Configure Aux Out via CrewWare
See the CrewWare Manual
Figure 32 Aux OUT Level
for more information about this process.
Operation - 63
