Figure 34
Right Side View, N232 and
N262
Figure 35
Left Side View, N232 and
N262
Table 21
Legend to the right and
left side views
Physical Data of the VTT Compressor
Indicator
Description
1
Ceiling
2
Air space outlet minimum 225 mm (8.9")
3
Air space inlet minimum 225 mm (8.9")
4
Floor
