Environment Conditions,
Storage and Operation
Table 9
Environmental Conditions
Compressor Pressure
Limits
Maximum Design
Pressure
Table 10

Maximum Design Pressure

Maximum Operating
Pressure
Table 11
Maximum Discharge
Pressure - All Models
Mains AC Input Supply
Voltage and Frequency
Table 12
Nominal and Acceptable
Voltage Ranges
Page 30 of 73
M-AI-VT-001-EN Rev.C.1

Environment and Application Boundaries

The compressor and drive module are designed for indoor applications only and should be stored
and operated within the following conditions:
Condition Type
Enclosures and Cover Type
Storing/Shipping temperature
Operation
Temperature
Relative Humidity
Maximum wet bulb temperature
Altitude
Maximum Altitude Above Sea Level without De-rating
Maximum Operating Temperature at:
2000 m (6000 ft.)
3000 m (9000 ft.)
The Drive Module should not be installed in environments with airborne liquids, particles, or gases capable of
affecting and damaging the electronic components.
Failure to take the necessary protective measures increases the risk of stoppages, thus reducing the life of the
drive module.
The maximum design high-side pressure for the compressor is shown in Table 10.
Certification
-NC (UL/ETL)
The maximum pressure that the compressor
can operate is regulated directly by two control
settings: Warning Limit and Fault Limit.
Type
Maximum Pressure Warning Limits
Maximum Pressure Fault Limits
VTT series compressors are designed to operate
within an acceptable rated voltage and frequency.
The tables below specify the acceptable supply
voltage and frequency ranges. Using a supply
Drive Module
N165 T5
N232 T5
N262 T5
N165 T5
N232 T5
N262 T5
Compressor IP24 Drive IP54=System IP24
Compressor IP24 Drive IP21=System IP21
-25°C to 70°C (-13°F to 158°F)
0°C to 40°C (32°F to 104°F)
5% to 95% non-condensing
29°C (84°F)
1000 m (3000 ft.)
38°C (100° F)
36°C (97° F)
• • • CAUTION • • •
kPa(g)
1400
The discharge pressure warning and fault limits
are defined in Table 11.
kPa(g)
1190
1240
voltage/frequency at or beyond the range limit
will cause the compressor to shut down. The +/-
10% is intended for the nominal voltage and is
not intended for the entire voltage range.
Nominal Voltage
380
400
460
380
400
460
380
400
460
575
575
575
Condition
psig
203
psig
173
180
Acceptable Voltage Range
342-418
360-440
414-506
342-418
360-440
414-506
342-418
360-440
414-506
518-632
518-632
518-632
