Figure 27
Bottom View
Physical Data of the VTT Compressor
320 (12.59")
76 (2.99")
6 (.23")
CROSS SECTION OF THE CHANNEL
Rails Details
Material AL 6061-T6 Channel
72 x 38 x 6.35 (3' x 1' . 5" x
Dimensions (Size)
0.25")
561 (22.08")
